Side 1/16
KXMA800.5
Manual del Propietario | Español
AMPLIFICADOR DEL LA SERIE KXM.5
Benutzerhandbuch | Deutsch
VERSTÄRKER DER KXM.5-SERIE
Manuel d’utilisation | Française
AMPLIFICATEUR DE SÉRIE KXM.5
KXM
AMPLIFIERS
Owner’s Manual
2
KXM.5-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no
items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of
open ventilation for the amplifi er. Drill four holes using a 7/64” (3mm) bit and use the supplied #8 screws
to mount the amplifi er.
PERFORMANCE
MODEL: KXMA800.5
IMPORTANT SAFETY WARNING
PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER, SPEAKER, OR SUBWOOFER IN
A DISTORTED, CLIPPED OR OVER-POWERED MANNER CAN CAUSE YOUR AUDIO SYSTEM
TO OVERHEAT, POSSIBLY CATCHING FIRE AND RESULTING IN SERIOUS DAMAGE TO YOUR
COMPONENTS AND/OR VEHICLE. AMPLIFIERS REQUIRE UP TO 4 INCHES (10CM) OPEN
VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM)
CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE.
Model: KXMA800.5
RMS Power, and AMP1 AMP2
@ 14.4V, 4Ω stereo, ≤ 1% THD+N
@ 14.4V, 2Ω stereo, ≤ 1% THD+N
@ 14.4V, 4Ω mono, ≤ 1% THD+N
50W x 4
100W x 4
200W x 2
RMS Power, channelSUB
@ 14.4V, 2Ω mono, ≤ 1.5 % THD+N
@ 14.4V, 4Ω mono, ≤ 1.5 % THD+N
400W x 1
200W x 1
Length [in, cm] 12-3/4, 32.4
Height [in, cm] 2-1/8, 5.5
Width [in, cm] 8-5/16, 21
Frequency Response [Hz] 10Hz–20kHzAMPS 1-2:
SUB: 10Hz–160Hz
Signal-to-Noise Ratio [dB] >95dB, A-weighted, re: rated power
Input Sensitivity 250mV–10V
Selectable Electronic Crossover OFF/HP/LP, variable 10–5,000Hz with 10X switch; AMP 1:
24dB/octave
AMP 2: OFF/HP/LP/BP, variable HP 10–500Hz,
variable LP 40–5,000Hz with 10X switch; 24dB/octave
SUB: Variable LP 40–160Hz; 24dB/octave
KickEQ™ Parametric Bass Boost Boost - Variable 0-18db; Center Frequency - 40Hz
Subsonic Filter Variable 10–80Hz; 24dB/Octave
NOTE: 2017 KXM amplifi er subwoofer channels are 1Ω stable - power rating equivalent to 2Ω operation, +/- 10%
3
Install a fuse within 7” (18cm) of the battery and in-line with the power cable connected to your amplifi er.
POWER WIRING
source unit
high-level speaker
outputs
to amplifi er
shield
+
–
core conductor
KICKER KISL (optional)
from source unit high-
level speaker outputs
OR
to amplifi er
Model External Fuse
(sold separately)
Power/Ground Wire KICKER Wiring Kit
KXMA800.5 1 x 100 Ampere 4 Gauge PK4, CK4
RADIO
DETECT
12V
Wiring: The KXM amplifi er’s RCA inputs will receive either high or low level signals from your car stereo’s
source unit. A high-level signal can be run from the source unit’s speaker outputs to the stereo RCA
input on the end panel of the amplifi er using the KICKER KISL as shown. Alternatively, the signal can be
delivered to the amplifi er using the low-level RCA outputs on the source unit. Keep the audio signal cable
away from factory wiring harnesses and other power wiring. If you need to cross this wiring, cross it at a
90 degree angle.
battery
external fuse
remote turn-on (see page 6)
ABYC-compliant power terminals Amplifi er uses 304-stainless steel screws
and conformal coated PCB for increased
weather resistance
aluminum bottom plate
≤7”
(18cm)
