Side 1/6

Conference phones for every situation

US English

Quick Guide

Konftel 60W Conference Unit

secs

DESCRIPTION

Konftel 60W converts a system, DECT or cell telephone into a conference telephone using

OmniSound

, Konftel’s unique technology for optimal sound quality. The connection between

the telephone and Konftel 60W can be wireless via Bluetooth

. Konftel 60W can also be

connected to a computer and accessed using communication software, e.g. Skype

. The

handbook and Konftel’s website www.konftel.com offer suggestions for various accessories and

applications.

Adjusting the microphone sensitivity

The microphone volume can be adjusted during the call, but to avoid disturbing

the call, it may be best to adjust it during a test call after the telephone has been

paired.



Press and hold the mute button for 2 seconds until the LEDs start to ﬂash and

you hear a tone.



Increase the microphone volume using + and reduce it using –.

Adjust the microphone volume one level at a time until you can hear well in the

other end. Please note that too high a level may cause echoes and feedback.



Press the mute button to conclude setting the selected microphone volume.

Microphone, 360°

sound recording

Three LEDs

Blue – microphone on

Blue, ﬂashing – pairing

Red – microphone off

On/off

Answers

a call

Reduces

speaker volume

Mute

Switches off

the microphone

Increases

speaker volume

Trim

Tunes

the sound quality

Connection cable computer, 4 ft (1.5m)

(60W–computer)

Connection cable electricity, 19 ft (6m)

(60W–plug adapter)

Plug adapter

Connection cable elec-

tricity–mains socket

Switchbox

(60W–telephone handset)

Cable duct

Sockets for extra

microphones

Power supply

Line connection

Connection cable telephone, 9 ft (3m)

(60W–switchbox)

Holes for

wall bracket

Three speakers

For further information, please consult the manual on enclosed CD

secs

Plug adapter

Connection cable electricity,

19 ft (6m)

WIRELESS CONNECTION TO TELEPHONE VIA BLUETOOTH

Connecting

Bluetooth has a range of up to ten meters. Optimum

performance is achieved when the distance does not

exceed ﬁve meters.



Plug Konftel 60W in using the power adapter as

shown in the picture.

Adding a telephone (pairing)

Please note that Konftel 60W must not be switched on.



Press and hold the trim button for 2 seconds until the blue indicator lights start

to ﬂash.



Follow the instructions in your telephone handbook to add a new Bluetooth unit

to your telephone.



Select Konftel 60W in the list of units detected.



Enter the password 0000.

If the pairing was successful, a short audible signal will be heard and the LEDs will

stop ﬂashing. If the pairing does not work, repeat the steps above but press and

hold trim button for 4 seconds instead of 2. The blue LEDs then start ﬂashing more

slowly.

Answering a call



Press the on/off button when Konftel 60W rings (the LEDs ﬂash).

Making a call



Make a call with your telephone in the normal way.



Transfer the call to Konftel 60W as per the instructions in the telephone

handbook.

Transferring a call between Konftel 60W and a telephone



Press and hold the on/off button for 2 seconds to transfer the call back to your

phone.

Ending a call



Ending the call on your telephone.

Konftel 60W switches off automatically.

Disconnecting the Bluetooth link

If you do not intend to use the phone for a while, you can choose to disconnect the

link to save power. The link is automatically connected when the telephone rings or

you make a call.



Press the mute button to disconnect the Bluetooth link.

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Kontortelefon
Modell:	60W
Vekt:	700 g
Kabellengde:	6 m
Produktfarge:	Sort
Type strømforsyning:	2 V DC/230 V AC, 700 mA
Driftstemperatur (T-T):	5 - 40 °C
Modell/Type:	DECT telefon
Samsvar med industristandarder:	Ce, FCC, UL, CSA
Bildegalleri:	Nei
Nettverksgrensesnitt:	Bluetooth 1.1
Kompatibel med Mac:	Ja
Maksimal innendørs rekkevidde:	10 m
Trådløse forbindelser:	Ja
Tilpassbart bakgrunnsbilde:	Nei
Kamera inkludert:	Nei
Konferansesamtaler:	Ja
LED på baseenheten:	Ja
