Les nedenfor 📖 manual på norsk for Kool-It KCD-48 (2 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 3 personer og ble vurdert med 4.9 stjerner i gjennomsnitt av 2 brukere
Side 1/2
Durable Design
- Frameless all sided curved glass
- Sides, doors, shelves are transparent glass
- Inside cabinet is stainless steel finish
- Whole unit including cabinet and doors are
filled with high density polyurethane
insulation
Energy Efficient
- All units utilize R134a refrigerant which is CFC
and HCFC free
Superior Quality
Project Name:
Location:
Item:
Model:
Qty:
KCD Series
Tel.: 514.737.9701 / Toll Free: 888.275.4538
Fax: 514.342.3854 / Toll Free: 877.453.8832
sales@mvpgroupcorp.com • www.mvpgroupcorp.com
- Angled sliding rear door for easy access
- Front curved glass and oval shaped side
glass display case for product visibilty
- Elegant curved shaped front display glass
- Easy to use digital display temperature
control panel
- LED Lamps
Counter-top deli case
Curved Glass
KCD Series
KOOL-IT is a registered trademark of MVP Group.
Specifications subject to change without notice.
Warranty: 12 months parts & labor. Additional
48 months on compressor (parts only)
TECHNICAL DRAWINGS
MODEL
NUMBER
COOLING
TYPE
DESCRIPTION
KCD-36
Glass
Counter-top
Deli Case
Fan
Cooling
Tel.: 514.737.9701 / Toll Free: 888.275.4538
Fax: 514.342.3854 / Toll Free: 877.453.8832
sales@mvpgroupcorp.com • www.mvpgroupcorp.com
# OF
DOORS
2
# OF
SHELVES
1
CAPACITY
CUBIC FEET
4.3
EXTERNAL DIMENSIONS
(W x D x H in.)
COMPRESSOR
SIZE
1/2
VOLTAGE /
FREQUENCY
WEIGHT
(lbs.)
115 V
60 Hz
REFRIGERANT
R134a 183
KCD-48
Glass
Counter-top
Deli Case
Fan
Cooling
2 1 47 1/4 x 19 7/8 x 29 1/8
35 5/8 x 19 7/8 x 29 1/8
1/2
115 V /
60 Hz
AMPS
6.4
6.4
R134a 271
These units are designed for maximum performance in an air-conditioned area of 75ºF ambient temperature and
55% relative humidity. There must be adequate ventilation at the top, sides & rear of the unit for proper operation.
KCD Series
5.8
TEMPERATURE
RANGE
1ºC - 5ºC
34ºF - 41ºF
1ºC - 5ºC
34 ºF - 41ºF
35 5/8” 47 1/4”
KCD-36 KCD-48
7 1/2” 5 9/16” 15 7/8”
29 1/8”
14 3/4”
17 1/2”
19 7/8”
8 11/16”
8 5/8”
