P/N: 2900-301204 Rev 2 www.kramerAV.com
USER MANUAL
MODELS:
AFM-20DSP, AFM-20DSP-LE
20-Port Audio Matrix
Kramer Electronics Ltd.
AFM-20DSP Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 4
Defining AFM-20DSP and AFM-20DSP-LE 5
AFM-20DSP and AFM-20DSP-LE Front Panels 5
AFM-20DSP and AFM-20DSP-LE Rear Panels 6
Mounting AFM-20DSP / AFM-20DSP-LE 7
Connecting the 20-Port Audio Matrix 8
Connecting AFM-20DSP 8
Connecting AFM-20DSP-LE 10
Connecting to AFM-20DSP / AFM-20DSP-LE via RS-232 11
Operating and Controlling AFM-20DSP/AFM-20DSP-LE 12
Operating via Ethernet 12
Using Embedded Webpages 15
Browsing the AFM-20DSP Webpages 16
Using the Top Status Bar 18
Viewing the Matrix Area 20
Processing Audio Signals 22
Selecting Output Signals to Route to Amplifier Outputs 22
Linking Analog Inputs and Outputs 23
Processing a Signal 24
Routing Inputs to Outputs 37
Mixing Audio Signals 41
Defining Audio Settings 45
Defining Video Settings 46
Restarting and Resetting the Device 47
Defining Settings 49
Importing/Exporting Global Settings 49
Setting Access Security 49
Defining Communication Settings 52
Performing Firmware Upgrade 54
Setting Date and Time 55
Configuring Device Automation 56
Viewing Device Information 58
Upgrading Firmware 59
Technical Specifications 60
AFM-20DSP Technical Specs 60
AFM-20DSP-LE Technical Specs 61
Default Communication Parameters 63
Default EDID 63
Protocol 3000 65
Understanding Protocol 3000 65
Protocol 3000 Commands 66
Result and Error Codes 83
Kramer Electronics Ltd.
AFM-20DSP Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/AFM-20DSP or
www.kramerav.com/downloads/AFM-20DSP-LE to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
Position your Kramer AFM-20DSP / AFM-20DSP-LE away from moisture, excessive
sunlight and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
