P/N: 2900-301291 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VA-4X
HDMI Extender / Toolbox
Kramer Electronics Ltd.
VA-4X Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 2
Defining VA-4X HDMI Extender / Toolbox 3
Mounting VA-4X 4
Connecting VA-4X 5
Operating and Controlling VA-4X 6
Configuring Settings OSD Menu 6
Configuring EDID via EDID Manager 10
Upgrading Firmware 18
Technical Specifications 19
Default EDID 20
Kramer Electronics Ltd.
VA-4X Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/VA-4X to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
Position your Kramer VA-4X away from moisture, excessive sunlight and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which located on the bottom of the unit.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
