Side 1/6
INSTRUCTION
MANUAL
WHITE
LIQUID SOAP/SANITIZER DISPENSER
#158LAVAK09WH
READ ENTIRE MANUAL BEFORE USE
Lavex Janitorial • 2205 Old Philadelphia Pike • Lancaster, PA 17602
07/2020
INSTRUCTION MANUAL2
PART DIAGRAM
TOP VIEW
BOTTOM VIEW
SPECIFICATIONS
Top Cover
Swiveling Cover
Fluid Input
Body
Indicator
Outlet
Hex Key
Battery Box
Wall Mounting Panel
Opening Lock
Setting Button
Anti-theft Lock
Battery Box Cover
Anti-theft Screw
Sensor Window
Outlet
VOLTAGE DC6V/(4) AA Batteries
VOLUME 28.7 oz. (850mL)
AMBIENT TEMPERATURE 32°-113°F (0-45°C)
SUPPLY 5 Adjustable Levels: 0.01-0.08 oz. (0.5-2.5 mL)
SENSING DISTANCE 2-3.5 in. (5-9 cm)
MATERIAL ABS Plastic
INSTRUCTION MANUAL3
IMPORTANT SAFETY INSTRUCTIONS
PACKING LIST
The following instructions must be followed to ensure optimal unit condition
and extended lifespan
Instructions must be followed carefully while installing the unit.
Always use new, identical batteries when installing unit.
Ensure that mounting surface is flat and clean before installing.
Ensure that the unit is installed at least 25 cm above the nearest surface to avoid sensing errors.
Each unit is to be installed by a qualified professional.
Do not install unit directly above reflective surfaces.
This unit is intended for indoor use only.
Children using the unit must be accompanied by an adult to avoid injury or malfunction
Please ensure proper disposal of depleted batteries
Keep unit dry at all times to avoid electrical malfunction
This unit contains electrical devices and valves, handle with care.
Disassemble unit with care to avoid damaging liquid feed line
Only clean unit with neutral detergents, and dry with a soft cloth
Do not clean unit with water or non-neutral detergents to avoid surface damage or internal
electrical failure. Only clean sensing area on underside of unit with a soft, dry cloth to avoid
sensing errors.
Unit must be installed at least 14" above surfaces to avoid sensor malfunction.
TO REDUCE RISK OF INJURY OR UNIT MALFUNCTION,
OBSERVE THE FOLLOWING INSTRUCTIONS
Ensure that all items below are included with our dispenser upon delivery.
If any parts are missing or damaged, contact your distributor.
Item specifications are subject to change over time.
If there are any issues with installation, contact your distributor.
The unit and main components are shipped sealed in bags. Open with care to avoid damages.
(1) Automatic Soap Dispenser
(1) Wall Mounting Panel
(3) Expansion Screws
(3) ST4x25 Screws
(1) Key
(1) User Manual
(1) Certificate of Qualification
WARNING
CAUTION
