User Manual

USB 3.0 enclosure for a SATA HDD

1. Specifications

LC-25U3-Diadem

Silent Power Electronics GmbH

Formerweg 8

47877 Willich

support@lc-power.com

www.lc-power.com

(6,35cm/2,5“)

Thank you for purchasing the hard disk drive enclosure from

LC-Power. Please read the manual before usage.

Specifications may be subject to change without prior notice.

Hard disk drive enclosure for a 6,35cm/2,5“ SATA HDD

- USB 3.0, downwardly compatible to USB 2.0 and USB 1.1

- For a 6,35cm/2,5“ SATA hard disk drive up to 1TB

- Chipset for S A 6Gb/s (for SATA I/II/III)AT

- LED status indicator

- Plug'n'Play

Nominal data transfer rate:

- Superspeed up to 5Gb/s (USB 3.0)

- Highspeed up to 480Mb/s (USB 2.0)

- Fullspeed up to 12Mb/s (USB 1.1)

System compatibility:

Windows XP/Vista/7/8, Mac OS 9.1, Linux 2.4 or higher

Included in delivery:

Enclosure, USB 3.0 cable, mounting material and manual

2. Installation

3. Notes

Avoid direct sunlight and a high temperature environment, keep

the enclosure far away from fire and heat sources.

Keep it in dry places, keep it away from corrosiveness causing

materials.

4. Service

The product has a two year warranty period from the date of

purchase, service issues will be handled by your dealer.

If the enclosure is damaged due to improper operation, the

warranty period expires immediately.

The enclosure supports most hard disk drives.

Incompatibility to a certain individual hard disk drive is not a reason

for repair or replacement.

We recommend that parents should guide their children using the

item, strictly following the notes in this manual.

Check www.lc-power.com or contact us by e-mail at

support@lc-power.com.

www.lc-power.com

- Height up to 12,5 mm

Step 1:

Unscrew both screws on the side of the enclosure and remove

the circuit board.

Step 2:

Carefully connect a 6,35cm/2,5“ SATA hard disk drive (not

included in delivery) with the matching connector of the PCB

interface. Move the PCB interface and the hard disk drive into the

enclosure and fix the interface with the screws to the enclosure.

Germany

Produkspesifikasjoner

Merke:	LC-Power
Kategori:	Ikke kategorisert
Modell:	LC-25U3-Diadem
Vekt:	200 g
Bredde:	79 mm
Dybde:	135 mm
Høyde:	16 mm
Materiale:	Aluminium, Plastic
Kompatible operativsystemer:	Windows XP\r\nMac OS 9.1\r\nLinux 2.4 +
Maksimal lagringskapasitet:	1 TB
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Sort
Kabler inkludert:	USB
Støttede lagringsgrensesnitt:	Serial ATA, Serial ATA II, Serial ATA III
Antall lagringsdrivere som støttes:	1
Plugg inn og spill:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) antall porter:	1
Lagringsstasjonens størrelse:	2.5 "
