VOI-8001

VOI-8002

VOI-8003

8-Port H.323/SIP VoIP Gateway

User Manual

Ver. 1.00-0608

Table of contents

CHAPTER 1. INTRODUCTION .............................................................. 3

1.1 OVERVIEW ..........................................................................................................3

1.2 PACKAGE CONTENTS...............................................................................................3

1.3 KEY FEATURE .......................................................................................................4

CHAPTER 2 GETTING STARTED ......................................................... 5

2.1 FRONT PANEL.......................................................................................................5

2.2 REAR PANEL ........................................................................................................ 6

CHAPTER 3 CONFIGURATION............................................................ 7

3.1 CONNECTION ....................................................................................................... 8

3.2 SYSTEM STATUS .................................................................................................. 10

3.3 REGISTER SERVER ............................................................................................... 11

3.4 VOIP CALL OUT.................................................................................................. 12

CHAPTER 4 WEB UI MANAGEMENT ................................................. 14

4.1 ACCESS TO WEB UI ............................................................................................. 14

4.2 WEB UI MANAGEMENT .......................................................................................... 15

4.2.1 Overview.................................................................................................. 15

4.2.3 Register Server Setting............................................................................. 54

4.2.4 Auto Provision function ............................................................................. 60

4.2.5 Advance Setup ........................................................................................ 62

4.2.6 Application.............................................................................................. 74

4.2.7 System................................................................................................... 76

4.2.8 Route Function(/System Setup) ................................................................. 85

4.2.9 Backup/Restore ......................................................................................108

4.2.10 Save Modification.................................................................................111

Chapter 1. Introduction

1.1 Overview

The VOI-800x series VoIP Gateway is equipped with 8 standard phone ports, one

10/100BaseTX Fast Ethernet WAN port, and three 10/100BaseTX Fast Ethernet

LAN ports. With the integration of both voice and data, the offers ability to route

data information into network solution

VoIP Gateway has voice support that includes Quality of Service (QoS), voice

compression, echo cancellation, dynamic latency (jitter) buffers, silence

suppression, and comfort noise generation.

The VoIP Gateway is compatible with xDSL and Cable-modem Broadband

service providers with built-in support for DHCP Client, MAC Address Cloning,

PPPoE and multiple auto-provisioning methods.

1.2 Package Contents

- 8-Port VoIP Gateway

- CD User Manual

- Cat.5 Cable

- Power Adapter, 12VDC / 1.6A

Model No List

VOI-8001 8-Port FXS VoIP Gateway

VOI-8002 8-Port FXO VoIP Gateway

VOI-8003 4FXS+4FXO VoIP Gateway

Produkspesifikasjoner

Merke:	LevelOne
Kategori:	Ruter
Modell:	VOI-8002
LED-indikatorer:	LAN, Power, Ready, Status, WAN
Pakkevekt:	2280 g
Sertifisering:	FCC, CE
Inngangsspenning:	100 - 240 V
Støttede nettverksprotokoller:	UDP, TCP, NAT, BOOTP, TFTP, FTP, HTTP, TELNET, IEEE 802.3/ IEEE 802.3u
MAC-adressefiltrering:	Ja
Utgangsstrøm:	12 V
WAN-port:	Ethernet (RJ-45)
Dynamisk DNS (DDNS):	Ja
Pakkedybde:	92 mm
Pakkehøyde:	385 mm
Pakkebredde:	220 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	3
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 75 °C
Modulator:	DTMF
Relativ luftfuktighet under drift (H-H):	0 - 90
Ledelsesprotokoller/håndteringsprotokoller:	SNMP, SNTP, HTTP
Brennmur-sikkerhet:	Ja
Stemmekodekser:	CNG, G.168, G.711a, G.723.1, G.726, G.729A, G.729B, VAD
VPN-støtte:	PPTP & IPSEC
DoS-angrepsbeskyttelse:	Ja
Antall Foreign eXchange Office (FXO)-porter:	8
