LevelOne WUA-0600 Bruksanvisning

LevelOne netverkskort/adapter WUA-0600

Les nedenfor 📖 manual på norsk for LevelOne WUA-0600 (30 sider) i kategorien netverkskort/adapter. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/30

LevelOne

User Manual

Ver. 1.0.0-0802

WUA-0600

N_Max Wireless USB Adapter

Safety

FCC WARNING

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the

modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or

modification is made.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

CE Declaration of conformity

This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class B for ITE, the essential protection requirement

of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.

CE Marking Warning

Hereby, Digital Data Communications, declares that this (Model-no. WUA-0600) is in compliance with the essential requirements and other relevant

provisions of Directive 1999/5/EC.

The CE-Declaration of Conformity can be downloaded at:

http://www.levelone.eu/support.php

Table of Content

TABLE OF CONTENT.................................................................................................................V

INTRODUCTION .........................................................................................................................3

USER MANUAL OVERVIEW............................................................................................................3

UNPACKING AND SETUP..........................................................................................................4

FEATURES ..................................................................................................................................4

PACKAGE CONTENTS...................................................................................................................4

SETUP........................................................................................................................................5

HARDWARE INSTALLATION ....................................................................................................5

INSTALLATION PROCEDURE FOR USB ADAPTER.............................................................................5

LED INDICATOR ..........................................................................................................................5

CHECK THE INSTALLATION ............................................................................................................6

WPS BUTTON.............................................................................................................................6

SOFTWARE INSTALLATION .....................................................................................................7

WINDOWS 2000/XP/VISTA UTILITY INSTALLATION..........................................................................7

WIRELESS UTILITY CONFIGURATION...................................................................................11

PROFILE ...................................................................................................................................11

NETWORK.................................................................................................................................18

ADVANCED................................................................................................................................20

WMM.......................................................................................................................................21

WPS........................................................................................................................................22

RADIO SETTING.........................................................................................................................24

ABOUT......................................................................................................................................24

NETWORK PLANNING.............................................................................................................25

TECHNICAL SPECIFICATIONS ...............................................................................................27

Produkspesifikasjoner

Merke:	LevelOne
Kategori:	netverkskort/adapter
Modell:	WUA-0600
Wi-Fi:	Ja
Tilkoblingsteknologi:	Trådløs
Sertifisering:	CE, FCC
Kompatible operativsystemer:	Windows XP/2000/Vista
Frekvensområde:	2.4 - 2.4835 GHz
Vertsgrensesnitt:	USB
Maksimal dataoverføringshastighet:	300 Mbit/s
Antall kanaler:	13 kanaler
Dimensjoner (B x D x H):	32.1 x 83.7 x 14.6 mm
Link/Act LED:	Ja
Produktfarge:	Sort
Driftstemperatur (T-T):	10 - 50 °C
Samsvar med industristandarder:	IEE 802.11b/g/n
Modulator:	16-QAM, BPSK, QPSK
Sikkerhetsalgoritmer:	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Krav til strømforsyning:	DC 5V, 0.5A
Wi-Fi-bånd:	Enkeltbånd (2.4 GHz)
WLAN-støttede dataoverføringshastigheter:	300 Mbit/s
Minstekrav til systemet:	USB 1.1/2.0
Støttede dataoverføringsrater:	300/54/48/36/24/18/12/11/9/6/5.5/2/1 Mbps
Mottakersensitivitet:	Draft 802.11n:\n-65dBm @ 64-QAM, 40MHz\n-70dBm @ 64-QAM, 20MHz\n802.11g:\n-72dBm @ 54 Mbps\n802.11b:\n-86dBm @ 11 Mbps
Luftfuktighet, uvirksom:	5 - 90
Media tilkoblingsprotokoll:	CSMA/CA (ACK)
