70m C6 HDBaseT HDMI 18G & IR Extender

Transmitter & Receiver

User Manual English

Benutzerhandbuch Deutsch

Manuel Utilisateur Français

Manuale Italiano

No. 38213-4

lindy.com

Tested to comply with

FCC Standards

For Home and Office Use!

!!! IMPORTANT !!!

Only use a direct Cat.5e/6/7 cable connection between the

HDBaseT ports. Do not connect these ports to Network or

Ethernet equipment or any active components

!!!! WICHTIG !!!!

Verwenden Sie AUSSCHLIEßLICH eine direkte

Kabelverbindung zwischen den HDBaseT Anschlüssen

aber NIEMALS eine Netzwerkverbindung oder Ethernet

oder irgendwelche aktiven Komponenten

!!! ATTENTION !!!

N'utilisez qu'une connexion par câble Ethernet directe

entre les ports, sans passer par le réseau Ethernet, un

commutateur ou un quelconque périphérique connecté à

votre réseau !

!!! IMPORTANTE !!!

UTILIZZATE UN CAVO DEDICATO PER LA CONNESSIONE

TRA LE DUE UNITA', NON COLLEGATELO AD UNA RETE

ETHERNET O AD ALTRI COMPONENTI ATTIVI

User Manual English

Safety Instructions

! WARNING !

Please read the following safety information carefully and always keep this document with

the product.

Failure to follow these precautions can result in serious injuries or death from electric

shock, fire or damage to the product.

Touching the internal components or a damaged cable may cause electric shock, which

may result in death.

To reduce risk of fire, electric shocks or damage:

▪ Do not open the product. There are no user serviceable parts inside.

▪ Qualified servicing personnel must only carry out any repairs or maintenance.

▪ Never use damaged cables.

▪ Do not expose the product to water or places of moisture.

▪ This product is intended for indoor use only.

▪ Do not place the product near direct heat sources. Always place it in a well-ventilated place.

▪ Do not place heavy items on the product or the cables.

▪ Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket

Introduction

Thank you for purchasing from the 70m C6 HDBaseT HDMI 18G & IR Extender kit. This product has been

designed to provide trouble free, reliable operation. It benefits from both a LINDY 2-year warranty and free

lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future

reference.

The Lindy C6 HDBaseT HDMI 18G & IR Extender is a two-part high performance, reliable solution for

extending HDMI signals over long distances via Cat.6 network cable. This kit can be used with each other

or with a compatible Lindy HDBaseT splitter. For further information on this, please see your local Lindy

website.

HDBaseT is a globally recognised standard for high quality distribution of AV content and other

technologies, including power, control and ethernet, over longer distances via low cost Cat.6 or above

cable.

Supporting resolutions up to 4K Ultra HD, video can be viewed in stunning clarity, while additional support

for HDR (High Dynamic Range) allows content to be displayed with enhanced brightness, greater contrasts

of blacks and whites and a much wider colour gamut. This provides a reliable solution for creating eye-

catching digital signage in retail, immersive displays at events or engaging setups in larger conference

rooms or lectures halls.

PoC (Power over Cable) functionality provides additional flexibility. This allows power to be supplied

alongside data through Cat.6 network cable in a point to point connection between the transmitter and

receiver, meaning only a single power supply is required at the transmitter unit. Ideal when power outlets

are limited at the receiver end of the installation. Featuring bi-directional IR ports at both sides of the setup,

the source equipment can be easily controlled from the display side, and the display can also be controlled

from the HDMI source side. Combined with CEC control, which allows commands from one main remote,

this extension system allows for complete and simple control for the user.

HDBaseT™ and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.

Please Note: The quoted lengths and resolutions are possible with a direct connection between

Transmitter and Receiver using good quality Cat.6 solid core cable. Using a different cable type, or

introducing wall plates, couplers or patch panels may result in a reduction of possible distances.

Produkspesifikasjoner

Merke:	Lindy
Kategori:	AV ekstender
Modell:	38213
Vekt:	345 g
Bredde:	157 mm
Dybde:	90 mm
Høyde:	20 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Pakkevekt:	847 g
Sertifisering:	CE, FCC, REACH & California Proposition 65
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Metall
HDMI-versjon:	2.0
HDMI inn:	1
RS-232 inngangsporter:	1
HDCP-versjon:	2.2
Driftsspenning:	24 V
Brikkesett:	VS010
HDBaseT-port:	Ja
Produktfarge:	Sort
Pakkedybde:	130 mm
Pakkehøyde:	70 mm
Pakkebredde:	220 mm
Kabler inkludert:	IR
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
DC-inngangskontakt:	Ja
CEC-gjennomgang:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 90
Fjern (IR)-utgang:	1
AC-adapter bunt:	Ja
Største båndbredde for port:	18 Gbit/s
Innput-strøm:	1 A
Fjerninngang (IR):	1
Maksimal overføring avstand:	70 m
Kabeltyper som støttes:	Cat6
RJ-45-utgangsporter:	1
Extended display identification data (EDID):	Ja
