M-Audio Oxygen 49 Bruksanvisning

M-Audio Midi-keyboard Oxygen 49

Les nedenfor 📖 manual på norsk for M-Audio Oxygen 49 (46 sider) i kategorien Midi-keyboard. Denne guiden var nyttig for 2 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/46

Oxygen Series

User Guide

AUDIO

Oxygen Series User Guide  2

1 Introduction

Congratulations on purchasing an M-Audio Oxygen Series keyboard. Oxygen keyboards now offer DirectLink, which

provides support for Digital Audio Workstations (DAW)

such as Pro Tools 8 by automatically mapping the track and

master volume sliders, slider buttons, pan knobs and transport controls to their corresponding functions in the program.

A single USB connection not only sends MIDI data to the computer, but also provides power to the keyboard. All

Oxygen Series keyboards function as class-compliant devices and will be recognized by your computer without the

need to install additional drivers. Simply use the included USB cable to connect the keyboard to an available USB port

on your computer and set the power switch to the On position.

Please refer to Section 5 of this Guide for more information on keyboard setup (including optional driver installation),

and configuration of your recording application.

2 What’s in the Box

The Oxygen Series keyboard packaging includes the following:

Oxygen Series keyboard

USB Cable

Printed Quick Start Guide

Oxygen Series disk

Please check www.m-audio.com for a current list of supported recording applications, the most recent DirectLink

installers, and configuration instructions. Applications not directly supported via DirectLink can be controlled by

using your recording application’s "MIDI learn" feature or by mapping the Oxygen controls manually. See

sections 8 and 9 of this guide for more information.

Produkspesifikasjoner

Merke:	M-Audio
Kategori:	Midi-keyboard
Modell:	Oxygen 49
Vekt:	2900 g
Bredde:	737 mm
Dybde:	239 mm
Høyde:	94 mm
Minimum RAM:	512 MB
Minimum prosessor:	1GHz
Støttede Mac operativsystemer:	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Antall taster på MIDI-tastatur:	49 taster
