Side 1/32
VACUUM ATTACHMENT
ACCESSOIRE POUR SOUFFLEUR
ABSAUGDÜSE
ACCESSORIO DI ASPIRAZIONE
VACUUM TOEBEHOREN
ACCESORIO DE VACÍO
SUGETILBEHØR
English / Français / Deutsch
Italiano / Nederlands / Español / Dansk
197235-3
INSTRUCTION MANUAL
(P2~P5)
Important:
This attachment is designed to be mounted on Makita blower. Before use, be sure to read
thoroughly both instruction manuals of this attachment and your blower.
Any failure to follow the indications of the manual may lead to serious accidents.
INSTRUCTIONS D’EMPLOI
(P6~P9)
Importante:
Cet accessoire est conçu pour être monté sur les sou󰀪eurs de la marque Makita.
Avant le démarrage, lisez attentivement le manuel d’utilisation de cet accessoire ainsi que ce-
lui de votre sou󰀪eur.
Une inobservation des instructions du manuel pourra causer des accidents sérieux.
BETRIEBSANLEITUNG
(P10~P13)
Wichtig:
Dieses Zubehör wurde für die Montage an ein MAKITA-Blasgerät entworfen.
Bitte lesen Sie vor der ersten Inbetriebnahme sowohl die Betriebsanleitung für dieses Zube-
hör als auch diejenige für das Blasgerät gründlich durch.
Das Nichtbefolgen der Anweisungen kann schwere Unfälle zur Folge haben.
ISTRUZIONI D’IMPIEGO
(P14~P17)
Importante:
questo accessorio è destinato al montaggio sui so󰀩atori Makita.
Prima di usarlo si raccomanda di leggere a fondo sia il manuale di istruzioni dell’accessorio
stesso sia quello del soffiatore. La mancata osservanza delle indicazioni fornite in questi
manuali potrebbe divenire causa di gravi incidenti.
GEBRUIKSAANWIJZING
(P18~P21)
Belangrijk:
Dit toebehoren is bedoeld om te worden bevestigd op de Makita bladblazer.
Voor gebruik dient u de handleidingen van dit toebehoren en van de bladblazer zorgvuldig door
te lezen. Niet opvolgen van de instructies in de handleidingen kan leiden tot ernstige ongeluk-
ken.
INSTRUCCIONES DE MANEJO
(P22~P25)
Importante:
Este accesorio está diseñado para ser montado en el soplador de Makita.
Antes de ponerlo en funcionamiento, asegúrese de leer bien los manuales de este accesorio
y su soplador. Si no observa las indicaciones contenidas en los manuales, pueden surgir ac-
cidentes graves.
DRIFTSVEJLEDNING
(P26~P29)
Vigtig:
Dette tilbehør er designet til at blive monteret på et Makita-blæseapparat.
Sørg for at læse brugsanvisningerne for både dette tilbehør og blæseapparatet omhyggeligt
igennem inden brug. Hvis nvisningerne i brugsanvisningen ikke overholdes, kan det medføre
alvorlige uheld.
2
English
Thank you very much for purchasing Makita Vacuum attachment. This
attachment is designed to be mounted on Makita blower mentioned be-
low.
Before use, please read this manual and instruction manual of your blow-
er, and pay special attention to safety during operation.
Attachable models:
BHX2500, BHX2501
WARNING!
You must not put on this vacuum attachment besides an application model.
SYMBOLS
It is very important to understand the following symbols when reading this instructions manual.
WARNING/DANGER Wear Eye and Ear Protection
Read, Understand and Follow Instruction
Manual
Emergency Stop
Protective Gloves must be Worn Severing of ngers or hand, impeller blade
Keep the Area of Operation
Clear of All Persons and Pets
CE mark
Table of Contents
Page
Symbols ..........................................................................................2
EU declaration of conformity .......................................................... 3
Designation of parts........................................................................3
Assembly instructions ..................................................................... 4
Operation method ........................................................................... 5
3
For European countries only
EU Declaration of Conformity
We as the manufacturers: Makita Europe N.V.,
Business address: Jan-Baptist Vinkstraat 2, 3070 Kortenberg, BELGIUM.
Authorize Kazuhisa Makino for the compilation of the technical le and declare under our sole responsibility that the product(s);
Designation: Vacuum Attachment
Designation of Type(s): 197235-3.
Fullls all the relevant provisions of 2006/42/EC
and also fullls all the relevant provisions of the following EC/EU Directives:
2000/14/EC
and are manufactured in accordance with the following Harmonised Standards:
EN 15503:2009+A1:2013+A2:2015.
Place and date of declaration: Kortenberg, Belgium, 28. 6. 2023
Responsible person: Kazuhisa Makino,
Director - Makita Europe N.V.
For United Kingdom only
Declaration of Conformity
We as the manufacturers: Makita Europe N.V.,
Business address: Jan-Baptist Vinkstraat 2, 3070 Kortenberg, BELGIUM.
Authorize Kazuhisa Makino for the compilation of the technical le and declare under our sole responsibility that the product(s);
Designation: Vacuum Attachment
Designation of Type(s): 197235-3.
Fullls all the relevant provisions of S.I. 2008/1597 (as amended)
and also fullls all the relevant provisions of the following UK Regulations:
S.I. 2001/1701 (as amended)
and are manufactured in accordance with the following Designated Standards:
EN 15503:2009+A1:2013+A2:2015.
Place and date of declaration: Kortenberg, Belgium, 28. 6. 2023
Responsible person: Kazuhisa Makino,
Director - Makita Europe N.V.
Importer: Makita (UK) Limited, Michigan Drive, Tongwell, Milton Keynes, Buckinghamshire, MK15 8JD, UK
DESIGNATION OF PARTS
5
1
2
3
4
6
7
DESIGNATION OF PARTS
1. Elbow
2. Vacuum Pipe A
3. Vacuum Pipe B
4. Arrow Mark
5. Dust Bag
6. Bracket
7. Screw
