Assembly Instructions
Model:
Description:
Part Number:
Assembly Time:
90 Minutes (1.5-Hours)
MBQRG2-S6R, MBQRG2-S7R, MBQRG2-S7RRC
Polaris Ranger 2P
1 Bojo or Panel Tool
2 T20 T25 T27 Torx Driver
3 T40 Torx Driver
4 9/16” Drill Bit
5 Drill
6 4mm Allen Wrench
7 10mm Socket
Tools Required
Page 1 of 16
It is always to best practice disconnecting your negative battery terminal prior to any electronics installations to avoid damaging
the vehicle’s electrical system. Before you begin, read through these instructions and check that all parts are present.
This installation may require specials skills and tools to complete. It may be necessary to seek a trained installation technician
to complete this installation. Please note that MB Quart cannot assume any responsibility for damage resulting from
incorrect installation.
Polaris Ranger Audio Roof
Parts List
No. Component Name Qty
1 1
1
1
1
1
1
1
1
1
5
4
4
4
4
4
4
4
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Parts List
Front Roof
Rear Lip
PSAP, USB / AUX Port
Antenna Kit
8" Zip Tie
Pulse Power Harness
Fused Power Harness
Fir Tree Zip Tie
Split Grommet
M8 x 60mm Hex Bolt
M8 x 35mm Washer
M8 x 30mm Rubber Washer
M8 Nylon Locking Nut
M6 x 25mm Hex Bolt with Thread Lock
M6 x 30mm Washer
M6 x 25mm Rubber Washer
16
50mm x 50mm x 1320mm Foam
17
17
17
25mm x 25mm x 900mm Foam
Radio and Dash Assembly
Disassembly Instructions
Page 2 of 16
• Remove two sections of front
headliner. Depending on year
and model, you might find
push pin clips, dome lights,
and T25 or T40 bolts.
• Unclip rear view mirror
harness from roof panel.
• Disconnect front door harnesses.
Unclip (4) fir trees that hold the
door harness to the roof. This will
be reused later if you have
power windows.
