Side 1/8
PAIRING DEVICES
In Bluetooth mode, device will be automatically discoverable. Open Bluetooth settings on your Bluetooth device and search for
MXASB35V3 MXASB35V3 . Connect device to on your Bluetooth device to pair.
WARRANTY
CONTACT INFO
122 GAYOSO AVE
MEMPHIS, TN USA 38101
TEC PORTH SUP
800-903-6979
SHOW US Y INSTALLOUR
WWW. MPHISC UDIO.USAME ARA
@ME ARAMPHISC UDIO
@ME ARAMPHISC UDIOUSA
Electronics limited warranty (including Memphis accessories) When purchased from an Authorized Memphis Dealer, Memphis warrants this product to be free from
defects in material and workmanship under normal use for a period of ONE (1) YEAR from date of original purchase (receipt required),THREE (3)YEARS years if installed by
an authorized Memphis dealer (receipt required). If this product is identified as “Refurbished” or “B Goods”, the warranty is limited to a period of THREE (3) MONTHS from
date of original purchase. In all cases you must have the original receipt. Should service be necessary under this warranty for any reason due to manufacturing defect or
malfunction during the warranty period, Memphis will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replace-
ments may have cosmetic scratches and blemishes. Discontinued products may be replaced with more current equivalent products. Warranty is valid only for the original
purchaser and is not extended to owners of the product subsequent to the original purchaser. Any applicable implied warranties are limited in duration to a period of the
express warranty as provided herein beginning with the date of the original purchase at retail, and no warranties, whether express or implied, shall apply to this product
thereafter. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving
antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet or a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the part responsible for
Compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
MXASB35V3
35” Clamp Mount Soundbar
Marine Grade Construction
MEMPHIS
A U D S I N C 5I O E 1 9 6
• RGB Illuminated Speakers With RGB Output
• Customizable Equalizer
• Optional Wired Remote (MXA1MCR)
• Backup Camera Input With Trigger Wire
• Subwoofer Output
• Zone 2 line Output
• Bluetooth, AUX, USB, Weatherband, AM/FM W/ RDS
For optimal performance, Memphis recommends using only Memphis Connection accessories. Outfitting
your system with properly sized Memphis Connection wire and accessories will dramatically boost your
listening experience and increase the durability of your Memphis Audio products.
For your safety, always inspect the mounting location carefully to ensure you are not drilling into any electrical,
hydraulic, fuel or fluid lines. Always check your speaker load with a multi-meter before connecting the amplifier.
Connecting any speaker load lower than the rated impedance of the amplifier will result in damage to the amplifier.
Damage of this nature is NOT covered under warranty. Please pay close attention to what connections are made to
the amplifier.
If you are uncertain or uncomfortable proceeding with your installation, please contact your local
Authorized Memphis Audio Dealer
MXASB35V3
• 18 FM Presets, 12 AM Presets
• Day and Night Mode illumination
• Wet Bonded 3” TFT color Display
• IP66 Water Resistant Rating
• Built-in 400 Watt Amplifier
• Plug & Play Solution!
• Protective Grill Included
FEA RESTU
READY TO TURN IT UP? READ THIS FIRST!
• Take 14 mm bolt with lock washer and place it through bottom of clamp and slightly thread into Dove tailed piece.
• Slide assembly into one of the three dove tail recessed areas placing the unit at the desired angle.
• Tighten bolt to securely hold bracket in place.
• Repeat this step for both included brackets. Both brackets must be used during installation.
• Use bracket top half and tighten down over bar using the four included bolts, two per clamp.
• Tighten until the unit is secure.
• Connect wires to power, ground, and optional Aux-in our Audio out.
WARNING
MOUNTING
T UBLE OOTINGRO SH
Model Number
Color
Speaker Size (x8)
RMS/Peak (w)
Dimensions (in)
Clamp fit (in)
Plug & Play/Universal Fit
MXASB35V3
Black
3”
200/400
36.06(L) x 3.46(w) x 4(h)
1.25“ - 2.25
YES (Power & Ground Connection)
SPECIFICATIONS
NO POWER
NO SOUND
OPERATION KEYS
DO NOT WORK
RADIO DOES NOT WORK
RADIO STATION AUTO-SELECT
DOES NOT WORK
IGNITION SWITCH NOT ON
FUSE IS BLOWN
VOLUME IS TURNED DOWN
WIRING NOT PROPERLY CONNECTED
BUILT-IN MICRO COMPUTER NOT
OPERATING PROPERLY DUE TO NOISE
ANTENNA CABLE NOT CONNECTED
SIGNALS ARE TOO WEAK
SWITCH IGNITION KEY TO ACC
REPLACE THE FUSE
ADJUST VOLUME KNOB UP
CHECK WIRING CONNECTION
PRESS RESET BUTTON
RECONNECT ANTENNA CABLE
SELECT A STATION MANUALLY
Memphis Audio built a 50+ year legacy in the audio industry engineering the highest quality products to produce
the best possible listening experience for our fans and loyal supporters. To fully appreciate our products we
recommend taking the time to read and follow the instructions in this manual. As always, we recommend all
installation and service to be performed by an authorized Memphis Audio dealer.
The Memphis MXASB35V3 soundbar is designed to make it easy to bring Memphis sound to any environment. This
unit is easy to install and features multiple mounting options allowing it to fit on a wide variety of machines. The
MXASB35V3 is IP66 rater to resist water and the elements allowing you to take Memphis sound wherever the trails
take you!
A U D I O S I N C E 1 9 6 5
