Side 1/2

Turn off your computer, unplug the power

cable then remove the case panel.

b. Connect the provided Bluetooth USB cable to

the adapter.

Note: If the Bluetooth USB cable is not correctly connected to

the motherboard, Bluetooth function won’t work even after

driver installation.

2 Connect to a Computer

c. Locate an available slot and remove PCI-E X1

the corresponding slot cover on the rear

panel. Then insert the adapter carefully.

d. Locate an available connector and 9-pin

carefully plug the Bluetooth USB cable into it.

WLAN Bluetooth

PCI Express Adapter

Quick Installation Guide

To continue, ip the page over.

Bluetooth USB cable

Adapter

Images may dier from your actual product.

1 Disable Bluetooth

a. Right-click , select , go My Computer Manage

to Device Manager.

b. Expand the Bluetooth node to nd your

existing Bluetooth device.

c. Right-click the existing Bluetooth device and

select .Disable

Note: Make sure you have disabled all existing Bluetooth

devices (both built-in and third party).

Bluetooth

Device Manager

Disable

Existing Bluetooth Adapter

Before You Start:

If you plan on using Bluetooth and already

have connected Bluetooth devices, proceed

with step 1. Otherwise, skip to step 2.

Produkspesifikasjoner

Merke:	Mercusys
Kategori:	Ikke kategorisert
Modell:	MA80XE
Bredde:	120.8 mm
Dybde:	226.3 mm
Høyde:	21.5 mm
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Tilkoblingsteknologi:	Trådløs
Nettverksstandard:	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11n
Vertsgrensesnitt:	PCI Express
Maksimal dataoverføringshastighet:	2976 Mbit/s
Komponent for:	PC/server
Produktfarge:	Sort
Beste Wi-Fi-standard:	Wi-Fi 6 (802.11ax)
Videoopptaksgrensesnitt:	WLAN / Bluetooth
Intern:	Ja
Wi-Fi-bånd:	Dobbelbånd (2.4 GHz / 5 GHz)
WLAN-støttede dataoverføringshastigheter:	574,2402 Mbit/s
