Amplifier Bypass Adaptor
120 70-1728
Revision 04/27/10
Red - 12 Volts Switched Power
Green - Left Rear Speaker Positive
Yellow - 12 Volts Constant Power
Orange/White - Dimmer
Black - Chassis Ground
Match wires below to the matching function of each wire on your receiver (refer to instructions
supplied with receiver). The wire colors of your new receiver may, or may not, match the wire colors
of the adaptor. Match adaptor and receiver wires by function, disregarding color.
Individually tape off any unused wires.
Make final wiring connections following instructions on the next page.
STEP 2 -- INSTALL
Plug harness into factory harness in vehicle.
*120701728*
Before starting, compare items on your invoice with items
received. Thoroughly check packing materials. If an item
is missing, please call:
Crutchfield Technical Support at 1-800-955-9094
Wires in the adaptor
are much longer than
shown in illustration.
This harness
connects at
the receiver.
White - Left Front Speaker Positive
Violet/Black - Right Rear Speaker Negative
Violet - Right Rear Speaker Positive
Yellow/Blue - Left Front Tweeter Positive
Gray - Right Front Speaker Positive
Gray/Black - Right Front Speaker Negative
Green/Black - Left Rear Speaker Negative
White/Black - Left Front Speaker Negative
White/Red - Subwoofer Negative
Yellow/Black - Left Front Tweeter Negative
Yellow/Orange - Right Front Tweeter Negative
Green/White - Subwoofer Positive
Yellow/Red - Right Front Tweeter Positive
Run this
harness
to the
amplifier
location.
STEP 1 -- CONNECT WIRES
If your receiver does not have a dimmer or
illumination wire, tape off the Orange/White wire.
IMPORTANT
Copyright 2010 Crutchfield Corporation
R
at 1-888-955-6000
