INSTALLATION INSTRUCTIONS FOR PART 70-7864DZ
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
APPLICATIONS
HONDA ACCORD
2003-07 Honda Accord adapter to adapt
the Metra 99-7864 kit for dual zone
climate control applications
Instructions
IMPORTANT: If rear window defogger function is desired, professional installation is
STRONGLY RECOMMENDED .Disconnect the negative battery terminal to prevent an
accidental short circuit.
1. Disconnect the negative battery terminal to prevent an accidental short circuit.
2. Disassemble the dash as per the 99-7864 instructions.
3. Connect the 22-way green plug of the dual zone harness to the installation kit and
connect the 22-way and 16-way green caps of the dual zone harness to their mates
in the vehicle.
* If rear window defogger function is not desired, tape off yellow/green
wire to prevent an accidental short circuit, then installation of the dual
zone harness is complete.
Small Flat Blade Screwdriver I Socket Wrench
TOOLS REQUIRED:
70-7864DZ
• For rear window defogger function to be retained, follow the steps below. Remember
that professional installation is STRONGLY RECOMMENDED.
1.
Follow steps 1-3 to install dual zone harness.
2.
Remove (1) Phillips screw from bottom of panel below steering wheel
unclip panel and remove
(FIGURE A)
3.
Unclip plastic cover panel below the dash and remove (FIGURE B)
4.
Using the 8’ yellow/green wire provided, connect the bullet connector to
the mating bullet connector on the dual zone harness.
5.
Route the yellow/green wire through the grommet on the firewall
(FIGURE C) with a wire puller, being sure to avoid any moving parts that
could damage the wire.
Interior Instructions
AB
DC
E
