Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/22/20 INST95-6555B
INSTALLATION INSTRUCTIONS
95-6555B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DDIN radio provision*
• Painted scratch resistant matte black
KIT COMPONENTS
• A) Radio trim panel • B) Cut template • C) Radio brackets • D) Screw cover • E) Phillips screws (2)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Cutting tool • 3/8” socket set
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-1817
Antenna Adapter: Not required
A B C D
E
Dodge Ram 1994-1997
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
* This kit can only be used with shallow mount radios, or radios which have an “L”
shaped chassis design, with the radio chassis at the top of the screen, like Sony
models XAV-AX100, XAV-AX1000, XAV-AX200, XAV-A500, and XAV-V10BT †
† Refer to the radio manufacturer for current models
1.800.221.0932
|
MetraOnline.com
2
DASH DISASSEMBLY
1. Remove the ashtray, then remove (2)
Phillips screws exposed. Remove the
ashtray bracket. (Figure A)
2. Slide the cup-holder out, then remove
(2) Phillips screws exposed. Remove the
cup-holder assembly. (Figure B)
(Figure A) (Figure C)
(Figure B) (Figure D)
3. Unclip, unplug, and remove the
dashboard trim panel. (Figure C)
4. Remove (2) 3/8” screws securing the
radio. Slide the radio out, then unplug
and remove. (Figure D)
Continue to Kit Preparation
