Side 1/16
99-740199-7401
AWAW-709NI-709NI
DWDW-7401-7401
INSTALLAINSTALLATIONTION
INSTRUCTIONSINSTRUCTIONS
TOOLS REQUIRED
Cutting tool
Phillips screwdriver
KIT COMPONENTS
Radio
Housing
Equalizer
Housing
Bracket
Set #4
(6) Long
Studs
(6) Nuts
Bracket
Set #3
Equalizer
Dummy Plate
APPLICATIONS
CAR PAGE
NISSAN
200SX 1984-88....................................................................1
Altima (NOT keeping the factory cupholder) 1993-97.... 2
Altima (keeping the factory cupholder) 1993-97.............3
Hardbody Pickup 1986.5-93..............................................4
Hardbody Pickup 1994-95.................................................5
Maxima 1987-88................................................................. 6
Maxima 1989-91................................................................. 7
Maxima 1992-94................................................................. 8
NX (upper dash) 1991-93...................................................11
Pathfinder 1987-93.............................................................4
Pathfinder 1994-95.............................................................5
Pulsar 1987-90................................................................... 9
Sentra 1987-90....................................................................10
Sentra (upper dash) 1991-94.............................................11
Stanza 1987-89...................................................................12
Stanza 1990-92...................................................................13
INST 7401
Bracket
Set #2
Bracket
Set #1
Faceplate
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
Spacer
Disconnect the negative battery terminal to
prevent an accidental short circuit. Remove
(1) #10 Phillips screws from each side of the
center console. Unsnap the coin tray and
remove (2) #10 Phillips screws exposed. Lift
the storage box carpet out and remove (2)
#10 Phillips screws exposed. Remove the
ashtray and (2) #8 Phillips screws exposed.
Remove the dash trim bezel. Remove (4)
screws securing the factory head unit and
disconnect the wiring.
1
NISSAN 200SX 1984-88
2
Using the scored lines as a guide, cut and
remove
the dashed portions of the
Faceplate.
1
3
Snap the converted Faceplate onto the front of
the Radio Housing.
Cut and remove all mounting tabs on
Bracket Set #4 EXCEPT tabs "B". The
mounting tabs can be identified by the
stamped letter on the back of each tab.
Skip to the Installation Instructions for
ALL VEHICLES on Page #14.
4
"B"
"B"
"B"
"B"
