Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 7/13/22 INST99-7613
INSTALLATION INSTRUCTIONS
U.S. PATENT # D704,697
99-7613
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. nsure that all installation
connections, especially the air bag indicator
lights, are plugged in before reconnecting
the battery or cycling the ignition to test this
product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
KIT FEATURES
• ISO DIN radio provision with pocket • ISO DDIN radio provision
KIT COMPONENTS
• A) Radio housing • B) Bracket set A • C) Bracket set B • D) ISO DDIN trim plate • E) #8 x 3/8" Phillips screws (4)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Cutting tool
TABLE OF CONTENTS
Dash Disassembly .............................................. 3-5
Kit Assembly
ISO DIN radio provision with pocket ...................6
ISO DDIN radio provision ................................. 6-7
(See page 2 for Table of Contents by model)
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7552
Antenna Adapter: • 40-NI12
A B C E
Nissan Multi-Kit 2007-2015
Visit MetraOnline.com for more detailed information about the product and up-to-date
vehicle specific applications
Visit Metraonline.com or AxxessInterfaces.com
for harness and interface options.
APPLICATIONS
Nissan
D
Juke 2011-2014
Rogue 2011
Rogue S 2012-2013
Rogue SV
(w/SL package)
2012-2013
Rogue Select
(w/lower model radio)
2014-2015
Versa 2007-2013
Versa S 2014
Versa S+ 2014
Versa SV base 2014
386.257.1187
|
MetraOnline.com
2
Juke 2011-2014
For manual climate controls:
1.
Lift up to remove the small knob on the slide
for “recirc/ fresh air”.
2. Using the panel removal tool, carefully unclip
and remove the trim from around the climate
controls. (Figure A)
Note: Climate controls stay in the dash.
3. Remove (2) Phillips screws securing the radio
trim panel. (Figure B)
4. Remove (4) Phillips screws securing the
radio, disconnect the wiring, and then remove
the radio. (Figure C)
Continue to Kit Assembly
For auto climate controls:
1.
Using the panel removal tool, carefully unclip and
remove the climate control panel. (Figure A-2)
2. Remove (2) Phillips screws securing the radio
trim panel. (Figure B)
3. Remove (4) Phillips screws securing the radio,
disconnect the wiring and then remove the
radio. (Figure C)
Continue to Kit Assembly
(Figure C)
(Figure A-2)
(Figure B)
DASH DISASSEMBLY
(Figure A-1)
TABLE OF CONTENTS
(cont.)
Nissan
Juke 2011-2014 ..............................................2
Rogue 2011 ....................................................3
Rogue S 2012-2013 ........................................3
Rogue SV (with SL package) 2012-2013 ......3
Rogue Select (with lower model radio)
2014-2015....................................................3
Versa 2007-2013 ............................................4
Versa S 2014 ..................................................5
Versa S+ 2014 ................................................5
Versa SV base 2014 .......................................5
