Side 1/12
AX-HYKIA1-SWC
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 4/18/22 INSTAX-HYKIA1-SWC
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer to the instructions included with
the aftermarket radio.
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder,
and heat shrink • Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Connections ........................................................ 2-4
Installation .............................................................5
Programming .........................................................6
Steering Wheel Control Settings ...................... 7-9
L.E.D. feedback ....................................................5
Changing radio type ...........................................7
Remapping .......................................................7-8
Dual assignment .............................................8-9
Troubleshooting .....................................................9
Hyundai/Kia Data Interface with SWC 2010-2016
APPLICATIONS
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains BlueLink
• Designed for amplified* and non-amplified models**
• Retains balance and fade†
• Micro-B USB updatable
HYUNDAI
Elantra * 2011-2016
Genesis Coupe * 2013-2016
Santa Fe * 2013-2016
Santa Fe Sport * 2014-2016
Sonata * 2011-2016
Sonata Hybrid * 2011-2015
Tucson * 2010-2015
KIA
Optima * 2011-2015
Optima Hybrid * 2011-2016
Sorento (with UVO) * 2011-2013
Sorento * 2014-2016
Soul * 2012-2013
Sportage 2011-2016
INTERFACE COMPONENTS
• AX-HYKIA1-SWC interface
• AX-HYKIA1-SWC harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
* Requires the AX-HYKIA-SPDIF (sold separately)
** Bristol Audio Systems not covered
† Non-amplified models only
* Without NAV
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
