Side 1/4
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
XSVI-9701-NAV
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 2/6/18 INSTXSVI-9701-NAV
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
TABLE OF CONTENTS
Connections to be made .......................................2
Installing the XSVI-9701-NAV ................................3
Polaris Slingshot Data Interface 2015-up*
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory USB
• Pre-wired ASWC-1 harness (ASWC-1 sold separately) *
• Retains balance and fade
• Micro “B” USB updatable
• XSVI-9701-NAV interface
• XSVI-9701-NAV harness
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
* For retention of Speed Dependent Volume Control only
2
CONNECTIONS TO BE MADE
From the XSVI-9701-NAV harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
The following (3) wires are only for a multimedia/navigation radio that requires these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
• Connect the USB jack to the aftermarket radio.
12-pin pre-wired ASWC-1 harness:
• This harness is to be used along with the optional ASWC-1 (sold separately) to retain Speed
Dependent Volume Control only. If the ASWC-1 is not being used, disregard this harness. If it
will be used, please refer to the ASWC-1 instructions for radio connections and programming.
Note:
Disregard the harness that comes with the ASWC-1.
