Operating Instructions
1
CS-1X8HDMSPL5 HDMI 2.0 1x8 HDMI Splitter, HDCP2.2
Supports 3D, 4Kx2K@60Hz(YUV 4:4:4), 18G, HDR, EDID
Operating Instructions
Notice
The information in this document is subject to change without notice. Every effort has
been made in the preparation of this document to ensure accuracy of the contents, but
all statements, information, and recommendations in this document do not constitute
the warranty of any kind, express or implied.
Features
Simultaneously displays an UItra Hi-Def source on up to eight UItra HD displays.
Supports resolutions up to UItra HD 4Kx2K(3840x2160@60Hz YUV 4:4:4 ).
Supports three kinds of EDID handling abilities.
Supports
HDCP2.2/1.4 Compliant.
Supports 36 bit Deep Color.
Supports LPCM 7.1, Dolby TrueHD, Dolby digital Plus, and DTS-HD Master
Audio.
Support 3D.
Bandwidth 18G.
Support HDR.
Support online firmware upgrade via Micro USB Port.
Package Contents
1 x HDMI Splitter
1 x 5V/1A DC Adapter
1 x User Manual
Operating Instructions
2
SPECIFICATIONS
Operating Temperature Range -5 to +40℃(+23 to +104℉)
Operating Humidity Range 5 to 90%RH (No Condensation)
Bandwidth frequency 18Gbps
2.2PCDHPCDH
)elamef(IMDHx1stroptupnI
)elamef(stuptuoIMDHx8stroptuptuO
Resolution outputs up to 4Kx2K(3840x2160@60Hz YUV 4:4:4)
Dimensions(LxWxH) 247.2x110x17mm
Power consumption 5W(MAX)
Transmission Distance 15m(Maximum)over standard HDMI cable/26AWG
g016thgieWteN
PANEL DESCRIPTIONS
1
Indicator of HDMI output
2
Firmware port
3
Switch to “Mixed EDID” mode
4
Switch to “Auto EDID” mode
5
Switch to “Copy EDID” mode
6
Indicator of Power input
7
Power on/off: press the up/down to open/close the device
8
Power input
9
HDMI output ports
10
HDMI input port
