Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 12/12/19 INSTJP-1014
INSTALLATION INSTRUCTIONS
JP-1014
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• Driver and passenger specific dash replacement sealed speaker pods
to install 6” to 6.75” speaker
• Mounting positions for Chrysler three hole mount used by specific
speaker manufacturers such as Alpine
• Sealed enclosure with a hole for the factory wiring grommet
• Includes necessary speaker harness adapter
KIT COMPONENTS
• A) Speaker pods (L&R) • B) Speaker harness adapter (2)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 8mm, 10mm, socket wrench
TABLE OF CONTENTS
Dash Disassembly ..............................................2-6
Kit Assembly ..........................................................7
Jeep Wrangler (JL) 2018, Wrangler 2019-Up
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
A B
1.800.221.0932
|
MetraOnline.com
2
DASH DISASSEMBLY
1. Unclip and remove the panel below the
steering column. Remove (2) Phillips
screw exposed. (Figures A,B)
2. Unclip, unplug, and remove the climate
control panel. (Figure C)
(Figure D)
(Figure E)
3. Remove (2) Phillips screws securing
the radio trim panel, then unclip and
remove. (Figure D)
4. Remove (1) Phillips screw securing the
dash pad, then unclip and remove.
(Figure E)
(Figure A)
(Figure B)
(Figure C)
