Metra. The World’s Best Kits.
®
MetraOnline.com
© COPYRIGHT 2024 METRA ELECTRONICS CORPORATION
INSTALLATION INSTRUCTIONS
JP-1018
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory r
adio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
• Driver and passenger specific lower dash grilles
• Cut templates and hardware
• ABS injection molded, silver painted surround
• Metal stamped grille insert
• Used with OE or JP-1014 speaker upgrade dash pods
• 1 year warranty from defects
KIT COMPONENTS
• A) Template (Left & Right) • B) Cut-in grilles (Left & Right) • C) Backing plates (Left & Right)
TOOLS REQUIRED
• Panel removal tool
• Phillips screwdriver
• 7mm and 13mm socket
TABLE OF CONTENTS
Left dash Disassembly ...................................... 2-3
Dash cut-in...................................................................4-5
Passenger side Disassembly.............................6-7
Jeep Wrangler (JL) 2018-2023,
Jeep Gladiator 2020-2023
Visit MetraOnline.com for more detailed information about the product and up-to-date
vehicle specific applications
KIT FEATURES
A
C
B
REV. 1/17/2024 1
Dash cut-in.......................................................................8
386.257.1187
|
MetraOnline.com
2
DASH DISASSEMBLY
1. Unclip and remove the panel below the
steering column. Remove (2) Phillips
screw exposed. (Figures A,B)
2. Unclip, unplug, and remove the climate
control panel. (Figure C)
(Figure D)
(Figure E)
3. Remove (2) Phillips screws securing
the radio trim panel, then unclip and
remove. (Figure D)
4. Remove (1) Phillips screw securing the
dash pad, then unclip and remove.
(Figure E)
(Figure A)
(Figure B)
(Figure C)
REV. 1/17/2024 INSTJP-1018 3
DASH DISASSEMBLY
5. Remove (8) Phillips screws securing the
instrument panel on the left side, and
airbag panel on the right side.
(Figure F, G)
6. Unclip the steering column shroud then
set aside. (Figure H)
Driver’s side removal:
7. Open the driver’s door, then unclip and
remove the panel on the side of the
dash. Remove (5) Phillips screws
exposed. (Figure I)
8. Remove (5) Phillips screws securing
the speaker panel, then unclip and
remove. (Figure J)
(Figure I)
(Figure F)
(Figure G)
(Figure H)
(Figure J)
Tip: Now would be an excellent time to install
a pair of JP-1014 6.5" speaker pods. For more
information scan the QR code below.
