INSTALLATION INSTRUCTIONS FOR PART XSVI-9004-NAV
METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
REV. 9/17/2014 INSTXSVI-9004-NAV
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• Providesaccessory(12-volt10-amp)
• RetainsR.A.P.(retainedaccessorypower)
• ProvidesNAVoutputs(parkingbrake,reverse,andspeedsense)
• PrewiredASWC-1harness(ASWC-1soldseparately)
• Retainsbalanceandfade
• Micro“B”USBupdatable
FEATURES
•Cuttingtool•Crimpingtool•Tape•Connectors
(example:butt-connectors,bellcaps,etc.)
TOOLS REQUIRED
Audi CAN Interface
2002-2013
XSVI-9004-NAV
APPLICATIONS
•XSVI-9004interface•LD-AX-XSVI-AU1harness•LD-AX-XSVI-AU2harness
INTERFACE COMPONENTS
Connections to be made
–
FromtheLD-AX-XSVI-AU1harness................... 2-3
–
FromtheLD-AX-XSVI-AU2harness................... 4-5
Installing the XSVI-9004-NAV
–
FromtheLD-AX-XSVI-AU1harness...................... 3
–
FromtheLD-AX-XSVI-AU2harness...................... 5
Troubleshooting
–
FromtheLD-AX-XSVI-AU1harness...................... 3
–
FromtheLD-AX-XSVI-AU2harness...................... 5
Table of Contents
AUDI
Applications below use
LD-AX-XSVI-AU1:
A3* 2006-2013
A4/RS4/S4with NAV 2005-2008
A4/RS4/S4 2007-2008
A4/RS4/S4* 2006
TT 2008-2013
Applications below use
LD-AX-XSVI-AU2:
A3** 2006-2007
A4/S4*** 2002-2006
A6 2004
allroad 2004-2005
TT 2002-2006
Note:
* Only for models with either a
Symphony Plus or NAV radio.
** With Concert radio (without NAV)
*** With Symphony radio
(without NAV)
XSVI-9004-NAV
2
From the LD-AX-XSVI-AU1 harness to the aftermarket radio
(a) From the 12-pin harness:
• ConnecttheRedwiretotheaccessorywire.
• ConnecttheOrangewiretotheilluminationwire,iftheaftermarketradiohas
noilluminationwire,tapeofftheOrangewire.
• ConnecttheBlue/Whitewiretotheampturnonwire(thiswiremustbe
connectedtohearsoundfromthefactoryamplifier).
Note: There is a Blue wire on the 40-pin harness to connect as well.
Thefollowingwiresareforaftermarketmultimedia/navigationradiosthatprovide
thesewires(ifnotrequired,tapethemoffanddisregardthem):
• ConnecttheLight Greenwiretotheparkingbrakewire(ifapplicable).
• ConnecttheGreen/Purplewiretothereversewire(ifapplicable).
• TheBlue/Pinkwirewillnotbeused,tapeitoffanddisregardit.
Note: This wire will be on the 40-pin harness instead.
(b) From the 40-pin harness:
• ConnecttheBlackandBlack/Whitewirestothegroundwire.
• ConnecttheYellow wiretothebatterywire.
• ConnecttheBluewiretotheampturnonwire(thiswiremustbeconnected
tohearsoundfromthefactoryamplifier).
Thefollowingwireisforanaftermarketmultimedia/navigationradiothat
providesthiswire,ifnotrequired,tapeitoffanddisregardit:
• ConnecttheBlue/Pinkwiretothespeedsensewire(V.S.S.),ifapplicable.
For non-BOSE systems:
• Disregardthe WhiteRCA,itwillnotbeusedinthisapplication.
• DisregardtheGrayRCA,itwillnotbeusedinthisapplication.
• ConnecttheGreenRCAtotheleftrearRCAoutput.
• ConnectthePurple RCAtotherightrearRCAoutput.
• ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.
• ConnecttheWhite/Blackwiretotheleftfrontnegativespeakeroutput.
• ConnecttheGray wiretotherightfrontpositivespeakeroutput.
• ConnecttheGray/Blackwiretotherightfrontnegativespeakeroutput.
Tapeoffanddisregardthefollowingwires,theywillnotbeusedin
thisapplication:
• TheGreen,Green/Black,Purple,Purple/Blackwires.
Connections to be made
