VDOM Monitor 3
Users Guide
Rev F, 01-26-21
VDOM Monitor 3 User's Guide, Rev. F, 01-26-21
2
Vectron • 100 Watts Street • Mount Holly Springs, PA 17065, USA
Revision History
Revision
Date
Description
A
04/16/2015
First Release - Preliminary
B
12/21/2015
Updated for Beta 0.3.x.x Releases
C
12/09/2016
Updated for Beta 0.4 Releases
D
10/26/2017
Updated for Beta 0.5 Releases
E
10/12/2018
Updated for Beta 0.6 Release
F
01/27/2021
Updated for Beta 0.6.3
VDOM Monitor 3 User's Guide, Rev. F, 01-26-21
Vectron • 100 Watts Street • Mount Holly Springs, PA 17065, USA
3
Contents
CHAPTER 1 INTRODUCTION..................................................................................................................................... - 4 -
1.1 INTRODUCTION ....................................................................................................................................................... - 4 -
1.2 TERMINOLOGY ........................................................................................................................................................ - 4 -
1.3 INSTALLATION ......................................................................................................................................................... - 4 -
CHAPTER 2 SOFTWARE LAYOUT ........................................................................................................................... - 5 -
2.1 MAIN WINDOW LAYOUT ................................................................................................................................................ - 5 -
2.1.1 Menu Bar .............................................................................................................................................................- 5 -
2.1.2 Task Selection Menu .........................................................................................................................................- 5 -
2.1.3 Task Panel ...........................................................................................................................................................- 6 -
Undocking ..................................................................................................................................................................................... - 6 -
Standard Controls........................................................................................................................................................................ - 7 -
2.1.4 Status Bar ............................................................................................................................................................- 7 -
2.2 OPTIONS WINDOW ........................................................................................................................................................ - 8 -
2.3 SERIAL DATA LOGGING SETTINGS WINDOW ................................................................................................................ - 8 -
CHAPTER 3 OPERATION ........................................................................................................................................... - 9 -
3.1 CONNECTING TO THE MODULE ..................................................................................................................................... - 9 -
3.2 TASK PANELS .............................................................................................................................................................. - 10 -
3.3 TASK PANEL DESCRIPTIONS ...................................................................................................................................... - 11 -
3.3.1 Status .................................................................................................................................................................- 11 -
Module Status (Legacy) ............................................................................................................................................................ - 11 -
Module Status ............................................................................................................................................................................ - 12 -
Data Monitor ............................................................................................................................................................................... - 13 -
(Legacy) Condition Register .................................................................................................................................................... - 14 -
Event Monitor ............................................................................................................................................................................. - 14 -
Performance ............................................................................................................................................................................... - 15 -
3.3.2 Configuration .....................................................................................................................................................- 17 -
Module Configuration (Legacy) ............................................................................................................................................... - 17 -
Module Configuration ................................................................................................................................................................ - 18 -
Configure Messages (Legacy) ................................................................................................................................................. - 20 -
Configure Messages ................................................................................................................................................................. - 21 -
Firmware Update ....................................................................................................................................................................... - 21 -
3.3.3 GNSS .................................................................................................................................................................- 22 -
Settings ....................................................................................................................................................................................... - 22 -
Satellite Tracking ....................................................................................................................................................................... - 22 -
Survey Mode .............................................................................................................................................................................. - 23 -
3.4 SERIAL DATA LOGGING .............................................................................................................................................. - 24 -
3.5 VDOM MONITOR OPTIONS ........................................................................................................................................ - 25 -
3.5.1 AutoConnect Options .......................................................................................................................................- 25 -
3.5.2 Application Settings ..........................................................................................................................................- 25 -
3.6 APPLYING FIRMWARE UPDATES ................................................................................................................................. - 26 -
3.6.1 Device Update Packages ................................................................................................................................- 26 -
3.6.2 Applying Updates .............................................................................................................................................- 26 -
Standard Update Process ........................................................................................................................................................ - 26 -
Update Failure Recovery .......................................................................................................................................................... - 28 -
CHAPTER 4 COMMAND LINE OPTIONS ................................................................................................................ - 29 -
Data Directory ............................................................................................................................................................................ - 29 -
Baud Rate ................................................................................................................................................................................... - 29 -
Command-Line Enabled Panels (CLEP) ................................................................................................................................ - 29 -
VDOM Monitor 3 User's Guide, Rev. F, 01-26-21
4
Vectron • 100 Watts Street • Mount Holly Springs, PA 17065, USA
Chapter 1
Introduction
1.1 Introduction
This document provides a brief overview of Vectron’s VDOM Monitor 3 software to
interface with select Vectron Disciplines Oscillator Modules. As VDOM Monitor is intended
to interface with several models and revision of devices, keep in mind that the availability
of individual features and options will depend on the connected device.
1.2 Terminology
VSIP
Vectron Serial Interface Protocol
VDOM
Vectron Disciplined Oscillator Module
Device or Target
The VDOM device sending reports and responding to commands.
Host
The device, typically a PC, sending commands to the VDOM device; a host may also be
another embedded system, typically communicating with the VDOM device via a UART.
Incoming
From Host to Target
Outgoing
From Target to Host
1.3 Installation
VDOM 3 is currently distributed via online download or provided on a USB Drive packaged
with module evaluation kits. VDOM Monitor is a stand-alone executable, which can be
executed from the USB drive or copied elsewhere and does not require any further
installation. VDOM Monitor requires the .NET Framework (Client Profile) version 4 or
higher, a redistributable copy of the .NET 4 Client Profile may be included with the VDOM
Monitor distribution, or it can be downloaded from Microsoft’s website. If downloading
from Microsoft’s website, it is recommended to download and install the latest available
version of the .NET Framework. Note that Windows 10 installations typically have .NET
Framework installed by default, and no additional installation is needed.
