PD-9x01GCO/AC

Single Port Outdoor Midspan User Guide

Introduction

Microchip’s PD-9001GCO, PD-9501GCO, and PD-9601GCO is a single-port IEEE

802.3bt Gigabit PoE outdoor

midspan that offers a cost-effective, IEEE

802.3at/bt compliant solution that guarantees 30W/60W/90W of power,

and ensures safe and reliable operation in outdoor environments for standard PoE data terminal. These midspans

support 10/100/1000 Mbps data rates and are powered through a wide range of AC inputs (100 V

to 240 V

These midspans are IP67-rated and have an extended temperature range to be installed outdoors. In a typical

installation, the midspans provide power to outdoor devices such as WLAN AP, WLAN Mesh, or an IP Camera.

These units offers surge protection for both the AC and the PoE ports ensuring that the indoor equipment is protected

from outdoor surges.

PoE midspan powers devices that are PoE enabled or equipped to receive PoE. These devices are called Powered

Devices (PDs).

Note: This user guide contains installation information for the PD-9001GCO, PD-9501GCO, and PD-9601GCO PoE

midspan units. These units are referred to as PD-9x01GCO PoE midspan units in the following section of this

document.

Features

PoE Midspans offer the following key features:

• Outdoor Rated: IP67

• Extended Temperature Range

• Supports 10/100/1000 Mbps Data Rates

• Standards Compliant: IEEE 802.3at/bt

• Plug and Play Installation

• Includes Integrated Surge/Lightning Protection

and its subsidiaries

User Guide

DS50003422A-page 1
