Side 1/24
Operator’s Manual
Mirage
®
Drop-in Induction Warmers and Rethermalizers
© 2024 The Vollrath Company L.L.C.
Part No. 2350219-1 ml
7/10/24
Thank you for purchasing this Vollrath
®
equipment. Before operating
the equipment, read and familiarize yourself with the following
operating and safety instructions. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE. Save the original box and packaging. Use this
packaging to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
• Plug only into grounded electrical outlets matching the nameplate
rated voltage.
• Do not use an extension cord with this equipment. Do not plug this
equipment into a power strip or multi-outlet power cord.
• As a precaution, persons using a pacemaker should stand back 12
"
(30 cm) from an operating equipment. Studies have shown that the
induction element will not disrupt a pacemaker.
• Keep all credit cards, driver licenses and other items with a magnetic
strip away from an operating equipment. The equipment’s magnetic
field will damage the information on these strips.
• Do not put water in the outer well of the warmer/rethermalizer. It is
intended to run dry. Water will damage the equipment and void the
warranty.
• Use only Vollrath induction-ready insets with this equipment. Failure
to use Vollrath induction-ready insets may damage equipment and
void the warranty.
• Do not spray controls or outside of equipment with liquids or
cleaning agents.
• Unplug when not in use.
• Keep equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or
around children.
• Do not operate if the equipment is damaged or is malfunctioning.
Table of Contents
Unpack the Equipment .................................................page 2
Clearance Requirements ..............................................page 2
Installation ...................................................................page 3
Operation .....................................................................page 4
Cleaning ...................................................................... page 5
Troubleshooting .......................................................... page 6
WARNING
CAUTION
Item No. Description
Plug
74701DW 7 Qt. Warmer
NEMA
5-15P
741101DW
11 Qt. Warmer
74701D
7 Qt. Rethermalizer
741101D
11 Qt. Rethermalizer
741101D
2
Mirage
®
Drop-in Induction Warmers and Rethermalizers Operator’s Manual
FUNCTION AND PURPOSE
All models are intended to keep food at proper serving temperatures.
For hot food holding, food must be at proper serving temperature when
placed into the drop-in. The equipment is not designed to cook raw
food.
800W models are intended to rethermalize refrigerated, previously
cooked food and hold hot food at safe serving temperatures.
Use only Vollrath induction-ready insets (items 88184 or 88204).
Failure to use Vollrath Induction-ready insets may damage equipment
and void the warranty.
This equipment is not intended for household, industrial or laboratory
use.
FCC STATEMENT
This equipment has been tested and found to comply with Part 18 of
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
To assure continued compliance, any changes or modifications not
expressly approved by the party Responsible for compliance could void
the user’s authority to operate this equipment.
UNPACK THE EQUIPMENT
1. Remove all packing material and tape, as well as any protective
plastic from the equipment.
2. Clean any glue residue left over from the plastic or tape.
CLEARANCE REQUIREMENTS
Drop-in
• Zero clearance between the sides of the drop-in and any
surrounding surface.
• Do not block airflow to the bottom of the equipment. Sufficient
airflow must be allowed. Blocking the airflow could cause the
equipment to overheat.
Control Box
• 4" (10 cm) behind the control box and any surrounding surface.
Product Dimensions
7 Qt. 11 Qt.
A 11⁷⁄₈(30.3) 13⁷⁄₈ (35.3)
B 10³⁄₈ (26.4) 12³⁄₈ (31.4)
C 10⁷⁄₁₆ (26.5) 12⁷⁄₁₆ (31.2)
7⁄8 (2.2)
12
5⁄16
B
9 ¼
(31.3)
(23.5)
C
A
5
(12.7)
¹³⁄₆₄
(.51)
2³⁄₁₆
(5.6)
3¹⁄₁₆
(7.8)
2⁵⁄₈
(6.6)
5¹³⁄₁₆ (14.8)
6⁷⁄₁₆ (16.4)
1½
(3.8)
³¹⁄₃₂
(2.4)
1¹⁵⁄₁₆
(4.9)
