Q24M: Camera Manual
HiRes Video Innovations
The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its
decentralized concept has made high-resolution video systems cost ecient.
MOBOTIX AG • D-67722 Langmeil • Tel: +49-6302-9816-103 • Fax: +49-6302-9816-190 • sales@mobotix.com
Allround Easy. Allround Secure.
High-resolution 180° Panorama
60.165_EN_V3_01/2013
Latest PDF file:
www.mobotix.com > Support > Manuals
2/164
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Q24M Camera Manual: Camera Data
High-resolution 180° Panorama
MOBOTIX Camera Data
Enter your camera data here.
Camera Model:
Camera Name:
Factory IP Address:
Current IP Address:
DHCP:
Admin User Name:
Admin Password:
Original Q24M image;
Wall mounted at a height
of 2.3 m in a bank
MOBOTIX Seminars
MOBOTIX oers inexpensive seminars that include workshops and practical exer-
cises.
For more information, visit www.mobotix.com
> Seminars.
3/164
Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
CONTENTS
Foreword 8
The MOBOTIX Concept 10
Innovative Hemispheric Technology 12
MOBOTIX Hemispheric Technology 14
Superior Storage Solution 16
Added Security Value 18
Cost Benefits And Technical Advantages 20
1 Introduction 22
1.1 Q24M Overview 22
1.2 Q24M Next Generation Hemispheric Technology 31
1.3 General MOBOTIX Camera Functions 32
1.4 Lens Options, Hardware And Software Features 38
2 Installation 42
2.1 Preparing The Installation 42
2.1.1 Wall-Mounted 43
2.1.2 Ceiling-Mounted 46
2.1.3 Mounting Options 49
2.1.4 Network Connection And Power Supply, UPS 50
2.1.5 Preparing The Camera Connections, Wall Outlets 51
2.1.6 Wiring, Fire Prevention, Lightning And Surge Protection 52
2.2 Q24M Basic/Secure: Delivered Parts, Components, Dimensions 54
2.2.1 Delivered Parts And Camera Components 54
2.2.2 Camera Housing And Connectors 55
2.2.3 Q24M: Dimensions Without Mounting Options 56
2.3 Available Q24M Accessories - Overview 57
2.4 Mounting The Camera Without Accessories 64
2.4.1 Mounting Instructions 64
2.4.2 Required Tools 65
2.4.3 Procedure 66
4/164
Q24M Camera Manual: Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
2.5 Mounting The Camera With The On-Wall Set 70
2.5.1 Mounting Instructions 70
2.5.2 On-Wall Set 71
2.5.3 Procedure 74
2.6 Mounting The Camera With The In-Ceiling Set 76
2.6.1 Mounting Instructions 76
2.6.2 In-Ceiling Set0 77
2.6.3 Procedure 80
2.7 Installing The Vandalism Set 82
2.7.1 Mounting Instructions 82
2.7.2 Vandalism Set 83
2.7.3 Procedure 86
2.8 Installing The Wall Mount 88
2.8.1 Mounting Instructions 88
2.8.2 Wall Mount 89
2.8.3 Procedure 92
2.9 Installing The Corner And Pole Mount 94
2.9.1 Mounting Instructions 94
2.9.2 Corner And Pole Mount 95
2.9.3 Mounting To A Pole 97
2.9.4 Mounting To A Wall Or Building Corner 98
2.9.5 Mounting The Wall Mount To The Corner And Pole Mount 99
2.10 Replacing The MicroSD Card 100
2.10.1 Removing The MicroSD Card 100
2.10.2 Inserting A MicroSD Card 101
2.11 Network And Power Connection 102
2.11.1 Notes On Cable Lengths And Power Supply 102
2.11.2 PoE Variables 102
2.11.3 Power Supply Using A Switch 103
2.11.4 Power Supply When Connected Directly To A Computer 104
2.11.5 Power Supply (PoE IEEE 802.3af) Using Power-over-Ethernet Products 104
2.11.6 Camera Startup Sequence 105
3 Operating The Camera 106
3.1 Manual and Automatic Operation– Overview 106
3.1.1 Manually Using A Computer In The 10.x.x.x IP Address Range 107
3.1.2 Automatically Using MxControlCenter Or MxEasy 108
3.1.3 Automatically Using DHCP 109
5/164
Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
3.2 First Images And The Most Important Settings 110
3.2.1 Manually Setting Up The Network Parameters In A Browser 110
3.2.2 First Images And The Most Important Settings In The Browser 112
3.2.3 First Images And Network Parameter Configuration In MxControlCenter 114
3.2.4 First Images And Network Parameter Configuration In MxEasy 119
3.2.5 Integrating And Displaying Cameras 120
3.2.6 Starting The Camera With The Factory IP Address 122
3.2.7 Starting The Camera With An Automatic IP Address (DHCP) 123
3.3 Virtual PTZ And Full Image Recording 124
3.3.1 Preparing The Virtual PTZ Function 124
3.3.2 Full Image Recording 126
3.3.3 Special Q24M Configuration In The Browser 128
3.4 MicroSD Card Recording 135
3.4.1 Introduction 135
3.4.2 Formatting The MicroSD Card 137
3.4.3 Activate Recording 138
3.4.4 Accessing Camera Data 139
3.4.5 Deactivating The Card Memory 139
3.4.6 Using A MicroSD Card In A Dierent MOBOTIX Camera 140
3.4.7 Limitations On Warranty When Using Flash Storage Media 140
3.5 Configuration In The Browser 141
3.5.1 Overview 141
3.5.2 General Browser Settings 141
3.5.3 Additional Configuration Options 144
3.6 Additional Notes 145
3.6.1 Weatherproofness 145
3.6.2 Password For The Administration Menu 145
3.6.3 Permanently Deactivating The Microphone 145
3.6.4 Starting The Camera With The Factory IP Address 145
3.6.5 Resetting The Camera To Factory Settings 146
3.6.6 Activate Event Control And Motion Detection 146
3.6.7 Deactivate Text And Logo Options 146
3.6.8 Deactivating The Camera Reboot 146
3.6.9 Browser 147
3.6.10 Cleaning The Camera And Lens 147
3.6.11 Safety Warnings 147
3.6.12 Online Help In The Browser 148
3.6.13 RoHS Declaration 148
3.6.14 Disposal 148
3.6.15 Disclaimer 149
6/164
Q24M Camera Manual: Contents
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Important Notes
Electrical Installation
Electrical systems and equipment may only be set up, changed and maintained by
a qualified electrician or under the direction and supervision of a qualified electrician
in accordance with the appropriate electrical guidelines.
Legal Aspects Of Video And Sound Recording
You must comply with all data protection regulations for video and sound monitor-
ing when using MOBOTIX products. Depending on national laws and the installation
location of the IP Video Door Station, the recording of video and sound data may be
subject to special documentation or it may be prohibited. All users of MOBOTIX
products are therefore required to familiarize themselves with all valid regulations
and comply with these laws. MOBOTIX AG is not liable for any illegal use of MOBOTIX
products.
Network Security
MOBOTIX products include all of the necessary configuration options for operation
in Ethernet networks in compliance with data protection laws. The operator is respon-
sible for the data protection concept across the entire system. The basic settings
required to prevent misuse can be configured in the software and are password-
protected. This prevents unauthorized parties from accessing these settings.
Never Remove The Dome
The MOBOTIX cameras S14D and S14M should never be operated without their
preinstalled transparent domes (sensor modules S14D and housing S14M) or protec-
tive lens screens (sensor modules S14D). The camera is no longer weatherproof
when operated without the domes or protective lens screens. The exposed metal
ring around the lens can become extremely hot when the exterior temperature is
high. Touching this ring can cause burns.
§
Additional Information:
www.mobotix.com
