Side 1/2
DC IN
DEPTH
Flanger
Vibrato
Phaser
MIX
DECAY
ModVerb
Main Features
1.True bypass footswitch:
Engages and disengages the effect
Hold the footswitch to activate Freeze
effect.
2.On/Off Led:
Displays the on/off status of the pedal.
Controls tap tempo. Tap the LED 2 or
more times to synchronize the modulation
rate to your desired tempo.
3.Mix control:
Adjusts the reverb and modulation
effect mix.
4.DEPTH
Adjusts the depth of the modulation.
5. Toggle switch
Selects between Flanger,
Vibrato and Phaser modulation effects.
6. DECAY
Adjusts the decay of the reverb effect.
7. DC in power jack: Input for power supply, use a 9V DC regulated power
supply , ,160mA,center pin negative.
8. Input jack : 1/4” audio jack for connecting to the input device or
instrument.
9. Output jack : 1/4” audio jack, effect output for connection to amp or
other devices.
*Notes Any specification’s update will not be amended in this manual.
PLEASE READ CAREFULLY BEFORE PROCEEDING
Interference with other electrical devices and Cleaning
Radios and televisions placed nearby may experience reception interference.
Operate this unit at a suitable distance from radios and televisions.
Clean only with a soft, dry cloth.
Power Supply
Please connect the designated AC adapter to an AC outlet of the correct voltage.
Please be sure to use only an AC adapter which supplies 9V DC, ,center
negative. Please do not use an AC adapter which supplies more than 9V DC.
Unplug the AC power adapter when not in use or during electrical storms.
Precautions
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metal, or other objects into this unit.
Take care not to drop the unit, and do not subject it to shock or excessive pressure.
9
3
Pedal layout
FCC certification
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
5
Part No:620010601
Modulation Reverb Pedal
ModVerb
Connections
Always turn off the power and all other equipment before connecting or
disconnecting. This will help prevent malfunction and damage to any of the devices.
Make sure to unplug all connection cables and power cords before moving this unit.
To avoid deformation, discoloration, or other serious damage,
do not expose this unit to the following conditions:
Direct sunlight
Magnetic fields
Excessively dusty or dirty location
Strong vibration or shock
Extreme temperature or humidity
High humidity or moisture
Heat sources
Frozen functionality
Small and compact size
True bypass
High quality reverb with 3 modulation types:Flanger, Vibrato, Phaser
DEPTH, DECAY, and MIX controls.
Tap tempo functionality
Modes:High quality reverb, 3 kinds of modulation effect with tap tempo and
frozen functionality.
Input:1/4” mono audio jack. Impedance: 470k Ohms
Output:1/4” mono audio jack Impedance: 100 Ohms
Power requirements: AC adapter 9V DC , center negative. Highly
recommend to use Mooer Micro Power.
Current Draw:160mA
Dimensions:93.5mm(D) x 42mm(W) x 52mm(H)
Weight:146g
Accessories:Owner’s Manual
调制混响单块
设备开连请务电源他设将有免故损害
另外确保机前有的线和线
场所
止变变色他严以下
光直射 •热源
温潮湿
尘或的地湿 度较
摇晃
干扰
使用本电视会造扰。使机时电视
使用干软的本机必要用稍湿的布切勿使粗糙
粉、料稀蜡、清洁化学浸渍
暴力使开关元件
让纸其他入机
不要使受到过度
*免责声更新不另通知
供应
使用正交流座连变压
使用内正 的 ±源变导致9V 10%
者其他不使雷雨拔下
ModVerb
DC IN
DEPTH
Flanger
Vibrato
Phaser
MIX
DECAY
ModVerb
7
6
9
1
3
2
5
8
种调响模选择式和 式。 FLANGER VIBRATO Phaser
节调混响果参DEPTH, DECAY MIX
LED TAP TEMPO调节 功能
踩脚 可产自激feedback
外壳MINI
9V电源
1.TRU E BYPA SS 钉:轻踩效果器开
开启效果果开启状
保持 活自激功feedback
松开踩时恢复正效果
2.LEDLED示效果器工作
TAP TEMPO按两下可根据
按下度调节所选调效果的速率。
3.MIX钮:节总体调制效和混响效
果与声的比例
4.DEP TH试调制类果的深度
5.三档拨档择当前使用调类效
的模别为 FLANGER
VIBRATO PHASER模式 模式
6.DEC AY钮:调节为混效果的深度。
7. 9VDC9V使用 流变压器内负外
160mA
8.INP UT1/4”声道
连接入信号。
9.OUT PUT出:1/4单声音频
接输出信号。
1 9V 160mA连接 负外
2 ModVerb INPUT OUTPUT连接信号入至 连接箱输接口
3踩下开启果器过提的旋节对参数效果
作模调制响效可独调节,附 和自式。TAP TEMPO
入:1/4 470k Ohms单声音频(阻
出:1/4 100 Ohms单声音频(阻
源供9V Mooer Micro Power直流压器负外),使用
作电160mA
寸:93.5mm(D) x 42mm(W) x 52mm(H)
量:146g
附件手册
Pa rt N o: 62 00 10 601
