Side 1/3
ASSEMBLY INSTRUCTIONS:
Please note: The lock knobs are screwed into end of the mid bar, please unscrew the knob
when you assembly the stand.
User’s Manual
Parts List of Unit:
Specifications Arm length: 40 cm Leg length: 56 cm Height: 60 to 86.5 cm Width: 60 to 90 cm
Weight: about 7kg Load bearing: 110 kg Width of level 2: 36 cm Height of 2nd level: 36 cm Material: steel
Manual Original
cp 1scp 2
2 pcs
2 pcs
Knob
2 pcs
Washers
Mid bar
3, Unscrew the knobs from the mid bar
knob
knob
knob
knob
Hole
Strap
knob
Hole
Second tier
4, Loose the Z-frame knob and insert the
second tier into arm, then tighten the knob.
1, Unscrew the knobs from the mid ba
2, Stand the two support Z-frame up
as the picture in above
6, Loose the knob, then adjust the angle
of arm, please tighten the knob again.
5, The assembled stand is the same as
the picture in above.
7, Loose the knob of mid bar, then adjust
the width of stand, please tighten the
knob into the hole after adjusting.
9, Screw the strap into keyboard if necessary
8, Loose the knob of support frame, then
adjust the height of stand, please tighten
the knob into the hole after adjusting.
10, Hang the headphone by holder if necessary
Second
tier
KSX4
1pc
Second
tier
Support Z-Frame
TRIPOD STAND FOR PIANO KEYBOARD
EN
Producent: Mozos Sp. z o. o. ; Sokratesa 13/37; 01-909; Warszawa; NIP: PL1182229831; BDO:000558288;
serwis@mozos.pl; mozos.pl; Made in China; Wyprodukowano w ChRL; Vyrobeno v Číně
