Side 1/5
MAR
Quick guide
MAR is a multichannel dual mixer module designed for its use on modular
synthesizers. Due to its DC-coupled connections,this module is capable of mixing
audio, CV and gate signals between ±10V.
• Mixer X
Four-channel mixer with gain control for each X channel. This mixer features 2
outputs, the mixer’s own output and its inverted. The output level is shown in the X
LED.
• Mixer Y
Four-channel mixer with gain control for the sum of the Y channels. This mixer
features one output. The output level is shown in the Y LED.
All potentiometers use logarithmic tape to have a good control with audio signals.
Description
Thank you for choosing the MAR Dual Mixer
for your Eurorack System.
NANO Modules - València 2018 ©
Powering up
Turn off the power of your modular synthesizer.
Double check the power cord polarity. The colored line on the cable must match
the “RED” mark at the PCB power connector.
If you plug the module backwards you might damage its electronic circuits.
Once you have checked all the connections, you can turn on your modular system.
If you notice any anomalies, turn your system off right away and check again your
connections.
1.
2.
3.
4.
MAR
