56050 - ( ) CanPRO
OPERATING INSTRUCTIONS
Important
1. To get the best operation and life from your machine, please read and comply with these instructions.
2. Clean machine thoroughly before and after each use using cleaning instructions below.
3. Minimize the use of alkaline cleaners as they may cause pitting and dulling of the finish.
Operation of CanPRO
1. Set side handle #20 in the unlock position.
2. Ensure that the Can Sitter is completely pulled out as shown in #36, and place can on the Table Base Can Sitter and gently lower the U-
shaped pin of the Cutter Housing Assembly #41 is over the lid. Be sure that the can is against the face of the can opener.
3. Lock the can in place by pushing down on the Side Handle. Turn Top Handle #4 in a CLOCK-WISE direction to open can. Warning:
Over-rotating beyond the initial seam cut may cause metal slivers. Incision point may be sharp. Train operators when to stop cutting and
how to remove lid safely.
Recommended Handle Turns:
Can Size Diameter Handle Turns
#2
3" 3 Revolutions
#5
5" 5 Revolutions
#10
6" 6 Revolutions
To Clean
WARNING: Cutting area must be kept clean at all times as indicated in the "CLEANING INSTRUCTIONS – USE OF BRUSH." Inspect and
clean the cutter and gripper with the included brush after each use to ensure proper operation. Failure to follow the included "Cleaning
Instructions" will cause damage and VOID WARRANTY.
Disassemble for Cleaning.
1. UNLOCK SIDE HANDLE #20. Slightly press Gripper Housing #7 face to pull out Side Locking Pin #16.
2. Tilt back Gripper Housing #7.
3. IMPORTANT: Pull out Cutter Housing Assembly #41 and clean with brush. Use brush provided to clean around outside of Cutter
Housing and inside the Mechanism Housing. Also use brush to clean all debris from around the Gripper.
4. After cleaning with brush, rinse off residue. SEE SEPARATE “CLEANING INSTRUCTIONS – USE OF BRUSH” FOR LOCATIONS.
Reassemble.
5. Insert Cutter Housing Assembly #41.
6. Return Gripper Housing #7 to closed position.
7. Slightly press Gripper Housing #7 face to re-insert the Side Locking Pin #16. (Ensure side handle #20 is unlocked.)
Note:
1. If cleaned in DISHWASHER, disassemble and clean with brush per above instructions.
2. Proper cleaning maximizes the life of the parts.
Replacing Cutter from Cutter Housing Assembly
1. Hold Cutter Shaft #26 with wrench and loosen Cutter Locking Bolt #31 (left hand thread) with another wrench by turning clockwise.
2. Remove Cutter Washer #30 and Cutter Spacer #29 and Cutter #28.
3. Replace with new Cutter.
4. Reverse steps 2 and 1 to re-assemble.
No. Part # Description
24
56052
Rubber Depth Control
25
56053
Adjusting Screw
26
56054
Cutter Shaft
27
56055
Cutter Housing
28
56029
Cutte
r
29
56024
Cutter Space
r
30
56056
Cutter Washe
r
31
56057
Cutter Locking Bolt
32
56058
Rubber Pipe Bumpe
r
33
56059
Square Pipe
34
56060
Plastic Pipe End
35
56043
Pin & Chain Assembl
y
36
56070
T
able Base Assembl
y
38
56063
Under Clamp
39
56064
T
able Base Screw
40
56065
Anti-Slip Rubber Pad
41
56022A
Cutter Housing Assembl
y
42
56023
Under Clamp Assembl
y
43
56068
Side Pin Assembly
44
56027
A
-B
Bottom Cutter Bearin
g
45
56027
A
-
T
T
op Cutter Bearin
g
46
56215
Gripper Bearin
g
No. Part # Description
1 56030
T
op Handle Knob Cove
r
2 56031
T
op Handle Knob
3 56032
T
op Handle Knob Screw
4 56033
T
op Handle
5 56034 Handle Screw
6 56027
T
op Handle Bearin
g
7 56035 Gripper Housin
g
8 56036 Gripper Shaft
9 56028 Grippe
r
10 56037 Bushing
11 56038 Bushing
12 56039 Locking Mechanism
13 56040 Locking Pin
14 56041 Allen Set Screw
15 56334 Gripper Housing Sprin
g
16 56026 Side Locking Pin
17 56044 Bushing
18 56045 Bushing
19 56046 Side Handle Shaft
20 56216 RH Side Handle
21 56048 Mechanism Housing
22 56049 Ball End Set Screw
23 56051 Adjusting Nut
CanPro Replacement Parts
Model Numbers : 56050- ( )
Product Warranty
Except as otherwise provided below, Nemco Food Equipment, LLC ("Nemco") warrants, to the original user, its can opener products (other
than cutters, bearing, and gripper) to be free of mechanical defects in the material and workmanship under "normal use" (define below) for the
shorter of the following periods: (a) one (1) year from the date placed in service by the original use, or (b) 18 months from the date of shipment
from its factory. The warranty provided herein shall be limited to parts and labor. Any determination that a product is defective or covered by
this warranty shall be made by Nemco, in its sole discretion. The determination of whether to repair or replace a defective, covered product, or
to refund the purchase price for the product, will be at Nemco's sole discretion. The warranty does not cover products used outside the United
States, or damages caused by accidents, misuse, negligence of and person other than Nemco, fire, flood, or other casualty. Any alteration to
the product or unauthorized repair voids this warranty. For purposes of this warranty, the phrase, "normal use" shall mean the use of the
product in connection with food in accordance with the product manual accompanying the product.
Nemco shall be responsible only for repairs or replacements of defective parts performed by Nemco's authorized service personnel. Authorized
service agencies are located in principal cities throughout the continental United States, Alaska, and Hawaii.
THE FOREGOING WARRANTY IS EXCLUSIVE AN IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. NEMCO EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTY THAT ANY OF ITS PRODUCTS IS MERCHANTABLE, FIT FOR A PARTICULAR PURPOSE, OR DOES
NOT INFRINGE ON THE RIGHTS OF ANY THIRD PARTY. THE FOREGOING WARRANTY SHALL BE NEMCO'S SOLE AND EXCLUSIVE
OBLIGATION. ANY PERSON'S (BUYER, USER OR OTHERWISE) EXCLUSIVE REMEDY AGAINST NEMCO AND NEMCO'S SOLE OBLIGATION,
FOR ANY AND ALL CLAIMS, WHETHER FOR BREACH OR CONTRACTM WARRANTY, TORT (INCLUDING WITHOUT LIMITATION
NEGLIGENCE), OR OTHERWISE, SHALL BE LIMITED TO NEMCO REPAIRING OR REPLACING THE PRODUCT, OR, AT NEMCO'S OPTION,
REFUNDING THE PURCHASE PRICE THEREFORE, IN NO EVENT SHALL NEMCO HAVE ANY LIABILITY FOR INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES. Any person desiring to make any claim against Nemco must do so within six (6) months after expiration of the
applicable warranty period, or such claim shall be forever barred.
Limited Warranty applies if the following instructions are followed.:
1. For foodservice use only.
2. Inspect and change cutter regularly.
3. Cutter must be kept clean at all times as indicated in the "Cleaning Instructions." Inspect and clean the cutter and gripper with the
included brush AFTER EACH USE to ensure proper operation. Failure to follow the included "Cleaning Instructions" will cause
damage and VOID WARRANTY.
4. Do not over rotate top handle to cut beyond the initial seam cut as this may cause metal slivers. If on the first cut the lid does not
open (check carefully as lid may be opened, however, due to the lid vacuum sealed it may be difficult to lift lid off) do not continue to
rotate handle.
5. Recommended Daily Use - maximum up to 50 cans per day depending on the usage (type of cans being opened up to No. 10 can
size)>
6. If used according to the recommended daily use and manual instructions, the cutter should last up to 2500 - 5000 cans depending
on handling and actual cans used. Note: If you open both ends of the can for recycling, please double you usage figure.
NEMCO FOOD EQUIPMENT
301 Meuse Argonne, Hicksville, OH 43526
Phone: (419) 542-7751 Fax: (419) 542-6690 Toll free: 1-800-782-6761
www.nemcofoodequip.com
