Omega Seamaster Planet Ocean 600M Bruksanvisning

Omega armbåndsurer Seamaster Planet Ocean 600M

Les nedenfor 📖 manual på norsk for Omega Seamaster Planet Ocean 600M (2 sider) i kategorien armbåndsurer. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/2

1 / 2

SEAMASTER

PLANET OCEAN 600 M OMEGA CO-AXIAL 42 MM

Steel on steel

Caliber

8500

232.30.42.21.01.001

Co-Axial escapement

]

Si14 silicon balance spring

Automatic

Chronometer

Time zone function

Sapphire crystal

Anti-reﬂective treatment on both sides

Sapphire crystal case back

Screw-in crown

Helium escape valve

4-year International Warranty

Water-Resistant to a relative pressure of 60 bar

(600 metres/2000 feet)

WATCH FUNCTIONS

The crown has 3 positions:

1. Normal position (wearing position): when the crown is positioned against the

case, the crown ensures that the watch is water-resistant.

Occasional winding: if the watch has not been worn for 60 hours or more, wind it

up with the crown in position 1.

2. Setting the time zone and correcting the date: pull the crown out to position

2. Turn the crown forwards or backwards, and the hour hand will move forwards

or backwards by 1-hour intervals. By passing the hour hand over midnight, the

date can be changed forwards or backwards. Push the crown back to position 1.

NB: when changing the time zone backwards, it is necessary to move the hour

hand back past 7 pm to ensure the date changes.

3. Time setting: hours – minutes – seconds. Pull the crown out to position 3. The

seconds hand will stop. Turn the crown forwards or backwards. Synchronise the

seconds by pushing the crown back to position 1 to coincide with a given time

signal.

2 / 2

HELIUM ESCAPE VALVE

How to use the helium escape valve? (ﬁg. 2)

In its normal position (ﬁg. 2.1), the OMEGA helium escape valve is perfectly

watertight thanks to the gaskets (B), but it is not functional, since it is screwed

down.

During the decompression phase, unscrew the crown of the valve in order to

release the mechanism (ﬁg. 2.2). The valve is now watertight from the outside.

As the interior pressure becomes greater than the exterior pressure, it pushes the

gasket (A) out of its seating, thus releasing the gas (ﬁg. 2.3). Once the pressure is

equalised, gasket (A) returns to its original position, pushed by the spring (C) (ﬁg.

2.2).

This operation is automatically repeated several times during the decompression

phase. Once atmospheric pressure is reached, screw down the crown of the valve

(ﬁg. 2.1).

Note: Even if the valve is unscrewed, and we strongly recommend that the valve

remains screwed down whenever the watch is immersed in water, the watch is still

water-resistant to a relative pressure of 5 Bar (50 metres). However, complete

water-resistance to the dial depth can only be achieved with gasket (B) and the

valve in the screwed down position.

Produkspesifikasjoner

Merke:	Omega
Kategori:	armbåndsurer
Modell:	Seamaster Planet Ocean 600M
Mekanismetype:	Mekanisk (automatisk opptrekk)
Kronometer:	Ja
Vanntett:	Ja
Støtsikker:	Ja
Kalendertype:	Dato
Produktdesign:	Tilfeldig
Kalender:	Ja
Klokketype:	Armbåndsur
Kjønnstype:	Hankjønn
Dekselfarge:	Rustfritt stål
Glasstype:	Krystall
Klokkeetuiets materiale:	Stål
Ur-innstilling:	12 timers
Urskivetype:	Analog urskive
Vannbestandig dybdenivå:	600 m
Armbånd, materiale:	Stål
Hovedfarge på reim:	Rustfritt stål
Boks-form:	Rund
Hovefarge på urskive:	Sort
Vannbestandig trykknivå:	60 ATM
Produsent av urverk:	Omega
Modell urverk:	8500
Anti-reflekterende maling:	Ja
Urviser farge:	Hvit
Husdiameter:	42 mm
Laget i Sveits:	Ja
Co-axial flukt:	Ja
Helium utløps-ventil:	Ja
Skru-inn krone:	Ja
Ripe-sikkert glass:	Ja
