TX-NR545

AV RECEIVER

Basic Manual

The Basic Manual includes information needed when starting up

and also instructions for frequently used operations. The Advanced

Manual has more detailed information and advanced settings.

CONTENTS

Front Panel ......................................................................... 3

Rear Panel.......................................................................... 4

Display ................................................................................ 4

Step 1: Connections �� 5

1 Connecting speakers....................................................... 5

･ Speaker layout ............................................................. 5

･ Height speaker types ................................................... 5

･ Instructions on how to connect speakers ..................... 7

2 Connecting the TV and players ....................................... 8

･ HDMI cable connection ................................................ 8

･ Connecting Components without HDMI ....................... 9

3 Other connections ......................................................... 10

Step 2: Initial Setup �� 11

1 AccuEQ Room Calibration .............................................11

2 Source Connection ........................................................ 12

3 Remote Mode Setup ..................................................... 13

4 Network Connection ...................................................... 13

Step 3: Playing Back ��15

1 Basic Operations ........................................................... 15

･ Part names and functions of the remote controller .... 15

2 Network Functions ......................................................... 16

3 AirPlay

......................................................................... 16

4 Bluetooth

..................................................................... 17

5 AM/FM Radio ................................................................ 17

6 Multi-zone ...................................................................... 18

･ Making Multi-zone Connection ................................... 18

･ Performing Multi-zone Playback ................................ 19

7 Quick Setup Menu ......................................................... 19

8 Other useful functions ................................................... 20

Troubleshooting ................................................................ 21

Specifications ................................................................... 22

Table of image resolutions ................................................ 23

Resolutions supported by HDMI ....................................... 23

Supplied Accessories ..........................................Back cover

En-2

Features

● Equipped with 7 ch amplifier

● Supports playback in Dolby Atmos format which

provides 360-degree placement and movement of

sounds including overhead sound

● Dolby Surround listening mode expands 2 ch, 5.1 ch or

7.1 ch source to available speaker configurations

● Equipped with 4K compatible HDMI IN/OUT jacks

● Supports the HDMI Standby Through function which

allows signal transmission from players to the TV in

standby state

● Supports HDCP2.2, a strict copy-protection for providing

high quality content (HDMI IN1 to IN3/HDMI OUT)

● Supports ARC (Audio Return Channel)

● Supports USB storage playback

● Supports variety of network functions such as Internet

Radio, DLNA, AirPlay etc.

● Supports Wi-Fi and Bluetooth

● Bi-Amping capability

● A/V Sync Function to correct deviation of audio and

video

● Multi-zone function which allows you to play a different

source in another room from the main room

● 32 bit DSP (Digital Signal Processor) with excellent

calculation performance

● Music Optimizer™ for compressed digital music files

● Phase Matching Bass System

● Automatic speaker setup available using supplied

calibrated microphone (AccuEQ Room Calibration)

● Supports playback of MP3, WMA, WMA Lossless,

FLAC, WAV, Ogg Vorbis, Apple Lossless, DSD, Dolby

TrueHD via network and USB storage device (the

supported formats will differ depending on the use

environment)

Refer to the back cover for supplied accessories.

Produkspesifikasjoner

Merke:	Onkyo
Kategori:	Mottaker
Modell:	TX-NR545
Vekt:	8600 g
Bredde:	435 mm
Dybde:	329 mm
Høyde:	173.5 mm
Bruksanvisning:	Ja
Bluetooth:	Ja
Wi-Fi:	Ja
Bluetooth-versjon:	2.1+EDR
Bluetooth-profiler:	A2DP, AVRCP
Tilkoblingsteknologi:	Ledning & Trådløs
Pakkevekt:	11500 g
Hodetelefonutganger:	1
3D:	Ja
On Screen Display (OSD):	Ja
Audio Return Channel (ARC):	Ja
Impedans:	16 Ω
HDMI inn:	6
FM-antenne:	Ja
Antall HDMI-utganger:	1
AM-antenne:	Ja
FM-bånd:	87.5 - 108 MHz
AC-inngangsspenning:	220-240 V
AC-inngangsfrekvens:	50 - 60 Hz
AirPlay:	Ja
Strømforbruk (standby):	0.15 W
Støttede lydformater:	AAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Produktfarge:	Sølv
Antall USB-porter:	1
Strømforbruk (vanlig bruk):	430 W
Lydinngang (V/H) inn:	8
Komponentvideo (YPbPr/YCbCr) inn:	2
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Signal-til-støy-forhold (SNR):	100 dB
Optisk stasjon inkludert:	Nei
Total Harmonic Distortion (THD):	0.08
Ethernet/bredbåndsforbindelse:	Ja
Lyd-utgang kanaler:	7.2 kanaler
Komposittvideo inn/sammensatt video inn:	4
Batterier medfølger:	Ja
Mottakertype:	Surround
Støttede radiobånd:	AM, FM
Sertifisert av Digital Living Network Alliance (DLNA):	Ja
Antall forhåndsinnstallerte stasjoner:	40
AM båndbredde:	522 - 1611 kHz
Innebygd lyddekoder:	Dolby TrueHD, DTS-HD Master Audio
Frekvensrekkevidde:	100 - 10000 Hz
Internett-radio:	Ja
Internettradiotjenester støttes:	Spotify, TuneIn
Digital optisk lydinngang:	2
Effekt pr. kanal (20-20KHz@8 Ohm):	- W
Digital koaksialinngang for lyd:	1
Dynamisk effekt pr. kanal (4 Ohm):	125 W
x.v.Color support:	Ja
Støtter dype farger:	Ja
Effekt pr. kanal (1KHz@6 Ohm):	120 W
Inngangssensitivitet:	200 mV
Pakningsstørrelse (BxDxH):	570 x 423 x 287 mm
Dynamisk effekt pr. kanal (8 Ohm):	85 W
Dempningsfaktor:	60
Dynamisk effekt pr. kanal (3 Ohm):	160 W
