Side 1/269

Tuning into a Radio Station

Tuning into stations automatically

1. Press TUNER on the main unit several times to select either "AM" or

"FM".

2. Press TUNING MODE so that the "AUTO" indicator on the display lights.

3. Press TUNING to start automatic tuning.

Searching automatically stops when a station is found. When tuned

into a radio station, the " TUNED " indicator on the display lights.

When tuned into an FM radio station, the "FM STEREO" indicator

lights.

No sound is output while the " TUNED " indicator is off.

When the signal from an FM radio station is weak: Radio wave may be

weak depending on the building structure and environmental conditions. In

that case, manually tune into the radio station of your choice by referring to

the next section.

AM/FM Radio Receiving Function

Tuning into stations manually

1. Press TUNER on the main unit several times to select either "AM" or

"FM".

2. Press TUNING MODE so that the "AUTO" indicator on the display goes

off.

3. Press TUNING to select the desired radio station.

The frequency changes by 1 step each time you press the button. The

frequency changes continuously if the button is held down and stops

when the button is released. Tune by looking at the display.

To return the display to "AUTO": Press TUNING MODE on the main unit

again. The unit is automatically tuned into an FM radio station. Normally

"AUTO" should be displayed.

Tuning into stations by frequency

It allows you to directly enter the frequency of the radio station you want to

listen to.

1. Press TUNER on the remote controller several times to select either "AM"

or "FM".

Produkspesifikasjoner

Merke:	Onkyo
Kategori:	Mottaker
Modell:	TX-NR838
Vekt:	15500 g
Bredde:	435 mm
Dybde:	198.5 mm
Høyde:	400 mm
Bluetooth:	Ja
Wi-Fi:	Ja
Bluetooth-versjon:	2.1+EDR
Bluetooth-profiler:	A2DP, AVRCP
3D:	Ja
Audio Return Channel (ARC):	Ja
Videooppskalering:	Ja
HDMI inn:	7
12V trigger:	Ja
Antall HDMI-utganger:	2
FM-bånd:	87.5 - 108 MHz
AC-inngangsspenning:	220-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.15 W
THX-sertifisert:	THX Select2 Plus
Produktfarge:	Sort
Antall USB-porter:	1
RS-232-port:	1
Strømforbruk (vanlig bruk):	720 W
Lydinngang (V/H) inn:	7
Komponentvideo (YPbPr/YCbCr) inn:	1
Strøminngang/AC (strøm) inn:	Ja
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Komponentvideo (YPbPr/YCbCr) ut:	1
Signal-til-støy-forhold (SNR):	106 dB
Optisk stasjon inkludert:	Nei
Total Harmonic Distortion (THD):	0.08
Ethernet/bredbåndsforbindelse:	Nei
Lyd-utgang kanaler:	7.2 kanaler
Komposittvideo inn/sammensatt video inn:	4
RS-232-tilkobling:	Ja
Mobil HD-lenke (MHL):	Ja
Display:	LCD
Mottakertype:	Surround
Støttede radiobånd:	AM, FM
Komposittvideo ut:	1
Sertifisert av Digital Living Network Alliance (DLNA):	Ja
RDS-mottaker inkludert:	Ja
Antall forhåndsinnstallerte stasjoner:	40
AM båndbredde:	522 - 1610 kHz
Innebygd lyddekoder:	Dolby TrueHD, DTS-HD Master Audio, THX Surround EX
Frekvensrekkevidde:	5 - 100000 Hz
Apple docking-kompabilitet:	Ja
Internett-radio:	Ja
Internettradiotjenester støttes:	Pandora, Spotify, TuneIn
Digital optisk lydinngang:	2
Effekt pr. kanal (20-20KHz@8 Ohm):	180 W
Digital koaksialinngang for lyd:	3
Dynamisk effekt pr. kanal (4 Ohm):	250 W
x.v.Color support:	Ja
Støtter dype farger:	Ja
Fjerninngang (IR):	1
Inngangssensitivitet:	200 mV
Pre-out tilkobling:	Ja
Wi-Fi klar:	Ja
Dynamisk effekt pr. kanal (8 Ohm):	150 W
Apple-docking:	Ja
Automatisk digital kanalsøking:	Ja
RDS-egenskaper:	PS, PTY, RT, TP
Video D/A-konverterer (DAC):	24-bit/192kHz
Pre-out kanaler:	7.2
Dynamisk effekt pr. kanal (3 Ohm):	300 W
