Osram Noxlite Bruksanvisning

Osram belysning Noxlite

Les nedenfor 📖 manual på norsk for Osram Noxlite (4 sider) i kategorien belysning. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/4

Product benefits

Quick installation

Easy change of housing, even between two different wattages

Product features

Efficient LED floodlight with high light output

Lighting panel can be swivelled round

Sensor funtion can be turned off via switch (manual luminaire switch-off required)

Available in two housing colors

Color temperature: 3,000 K

Color rendering index R

: > 80

Type of protection: IP44

Protection class: I

Lifetime (L70/B50): up to 35,000 h

Product datasheet

NOXLITE LED HP FLOODLIGHT 23 W WT

NOXLITE LED HP FLOODLIGHT II | Outdoor LED flood- and spotlights

Areas of application

Driveways

Garages

Yards

Pathway lighting

Outdoor use (only roofed areas)

NOXLITE LED HP FLOODLIGHT 23 W WT Page 1 of 4

Technical data

Electrical data

Operating mode ECG

Nominal wattage 22 W

Nominal voltage 220…240 V

Mains frequency 50/60 Hz

Photometrical data

Color temperature 3000 K

Luminous flux 1470 lm

Light color (designation) Warm white

Color rendering index Ra >80

Dimensions & weight

Length 189.0 mm

Width 167.0 mm

Height 203.0 mm

Colors & materials

Body material Aluminum

Product color White

Cover material Polykarbonát (PC), UV stabilizace

Temperatures & operating conditions

Ambient temperature range -20…+40 °C

Product datasheet

NOXLITE LED HP FLOODLIGHT 23 W WT Page 2 of 4

Additional product data

LDC typ polar

Equipped with lamp Yes

Type of cover Cover

Capabilities

Type of installation Direct mounting/Surface-mounted

Type of connection Terminal, 3-pole

Accessories Screw / Dovels / Washers

Certificates & standards

Protection class I

Type of protection IP44

Country specific categorizations

Order reference NXL LED HPFLOOD

Country specific information

Product code METEL-Code SEG number STK number UK Org

4052899917996 - 7761823 4516064 -

Product datasheet

NOXLITE LED HP FLOODLIGHT 23 W WT Page 3 of 4

Produkspesifikasjoner

Merke:	Osram
Kategori:	belysning
Modell:	Noxlite
Bredde:	90 mm
Dybde:	170 mm
Høyde:	90 mm
Integrerte sensorer:	Bevegelse sensor
Antall per pakke:	1 stykker
Lysstrøm:	430 lm
Fargetemperatur:	6000 K
Dag/natt-modus:	Ja
Strålevinkel:	60 °
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Grå
lys farge:	Kjølig hvit
Dimmbar:	Nei
Driftstemperatur (T-T):	-20 - 40 °C
Beskyttelsesfunksjoner:	Nei
Modell/Type:	Vegglys
Antall pærer:	1 ampuller
Kroppsmateriale:	Aluminium
Internasjonal beskyttelses (IP)-kode:	IP44
Beskyttelsesklasse:	II
Monteringsbeslag inkludert:	Ja
Total strøm:	8 W
Lyspæretype:	LED
Lampestyrke:	8 W
Levetid, pære:	30000 timer
Fjerndrevet:	Nei
Glassfarge:	Hvit
Color Rendering Index (CRI):	65
Dimmefunksjon:	Nei
Egnet for utearealer:	Garage, Patio
