Side 1/34
Release 1.1
www.audison.eu
AV uno
AV due AV quattro
AV 5.1k
OWNER’S
MANUAL
CAR AUDIO MULTICHANNEL
AMPLIFIER
OWNER’S MANUAL
AV 5.1k /
2
Index
1. INTRODUCTION ...........................................................................................................................................03
2. PACKAGING CONTENTS ..............................................................................................................................04
2.1 Available accessories ...............................................................................................................................04
3. SAFE SOUND ................................................................................................................................................04
4. PRECAUTIONS .............................................................................................................................................06
5. INSTALLATION .............................................................................................................................................07
6. REAR PANEL ................................................................................................................................................08
6.1 How to connect power cables .................................................................................................................08
6.2 How to replace the fuse ..........................................................................................................................09
6.3 How to connect the remote switch ..........................................................................................................09
6.4 Remote switching via SPK IN ................................................................................................................... 10
6.5 How to connect the Sub remote volume control ...................................................................................... 10
7. FRONT PANEL .............................................................................................................................................. 11
7.1 Input controls ........................................................................................................................................... 12
7.2 How to connect a source via PRE inputs ................................................................................................. 13
7.3 How to connect a source via the Speaker IN High-Level input ................................................................. 13
8. INPUT CONTROLS ....................................................................................................................................... 14
8.1 Control panel: switches and adjustments ................................................................................................. 14
8.2 Setting up filters ....................................................................................................................................... 15
8.2.1 A Channels ........................................................................................................................................ 16
8.2.2 B Channels ........................................................................................................................................ 16
8.2.3 C Channels ........................................................................................................................................ 17
8.3 Example: Front + Rear + Sub with IN A - IN B - IN C inputs .................................................................... 18
8.4 Example: Front + Rear + Sub with IN A and IN B inputs .......................................................................... 19
8.5 Example: Woofer + Mid HI + Sub with IN A inputs ....................................................................................20
8.6 Example: Woofer + Tweeter + Sub with SPK IN A inputs .........................................................................21
9. ACCESSORIES: AV bit IN ............................................................................................................................22
9.1 How to insert AV bit IN ............................................................................................................................. 23
9.2 Front panel .............................................................................................................................................. 24
9.3 Control panel display ................................................................................................................................ 25
9.4 How to connect the amplifier equipped with AV bit IN to the system ........................................................26
9.5 How to configure AV bit IN .......................................................................................................................27
9.6 Full DA Example: Front + Rear + Sub with Audison bit Ten D processor ..................................................28
9.7 Full DA Example: Woofer + Tweeter + Sub with Audison bit Ten D processor ..........................................29
9.8 Full DA Example: Front + Rear + Sub with Audison bit One processor ..................................................... 30
9.9 Full DA Example: Woofer + Tweeter + Sub with Audison bit One processor ............................................. 31
10. TECHNICAL SPECIFICATIONS .................................................................................................................... 32
OWNER’S MANUAL
AV 5.1k /
3
1. INTRODUCTION
Coming directly from the know-how of the exceptional Thesis line, Voce components takes the experience of listening
in the car to a new level of excellence.
Project innovation, advanced design, benchmark performance; the synthesis of consolidated know-how applied
to car audio systems. The Voce project was born to make Thesis sound quality available to a wider - but no less
demanding - audience. The development of these components took advantage of the major innovations introduced
while designing the Thesis line: analog and digital technologies combined using different classes of configuration for
amplifiers, reduction of the main sources of non-linear distortion, linearization of acoustic and electric loads, control of
cone and diaphragm resonance for speakers. To achieve these goals it was necessary to develop new circuit solutions,
increase heat capacity, design new moulds for baskets and diaphragms and define new assembly procedures and
quality control.
A delicate balance of analysis and refinement led us to results exceeding our expectations and set a new benchmark
for the category.
THE AV 5.1k AMPLIFIERS PROJECT
AV 5.1k, 1650 W (RMS) max, five-channels: with its hybrid design, it is the specialist amplifier for front + rear +
subwoofer or multi-amplified front + subwoofer systems. Its high-quality AB Class output stage provides two channels
with 250 W (RMS), combined with another pair of A class pure audio channels rated at 75 W (RMS), perfect for active
two-way front speaker systems. The D Class mono section provides 1000 W (RMS) for a powerful subwoofer output.
AV 5.1k also allows you to replace the analog input board with the digital one (AV bit IN).
