USER’S
MANUAL
2
AP F8.9 bit /
USER’S MANUAL
Index
1. PRODUCT DESCRIPTION / PRECAUTIONS .........................................................................................................................3
2. PACKAGE CONTENTS ............................................................................................................................................................... 3
3. AP F8.9 bit and DRC INSTALLATION ....................................................................................................................................4
4. CONNECTION PANEL DESCRIPTION ....................................................................................................................................5
1 POWER ................................................................................................................................................................................5
2 CTRL (REM IN-OUT. / CONTROL) ..................................................................................................................................6
3 SPEAKER IN........................................................................................................................................................................6
4 PRE IN..................................................................................................................................................................................7
5 SPEAKER OUT. ................................................................................................................................................................... 7
6 SUB OUT. .............................................................................................................................................................................8
7 OPTICAL IN .........................................................................................................................................................................8
8 DRC ...................................................................................................................................................................................8
9 USB . ..................................................................................................................................................................................8
10 UPGRADE OFF-ON. ...........................................................................................................................................................8
11 PRESET. ...............................................................................................................................................................................8
12 FUSE ...................................................................................................................................................................................8
13 LOGO STATUS....................................................................................................................................................................9
5. CONNECTIONS .........................................................................................................................................................................10
5.1 POWER SUPPLY AND REMOTE TURN ON. ...............................................................................................................10
5.2 INPUT SIGNALS ..............................................................................................................................................................11
5.3 DIGITAL OPTICAL IN INPUT SIGNALS .......................................................................................................................14
5.4 OUTPUT SIGNALS. .........................................................................................................................................................15
5.4.1 PRESET 0 DEFAULT: 3 WAY ACTIVE FRONT + REAR + EXTERNAL SUBWOOFER. ................................ 16
5.4.2 PRESET 1: 2 WAY ACTIVE FRONT + 2 PASSIVE REAR + SUBWOOFER ...................................................17
5.4.3 PRESET 2: 3 WAY ACTIVE FRONT + SUBWOOFER ......................................................................................18
5.4.4 PRESET 3: FRONT + REAR + SUBWOOFER ...................................................................................................19
5.4.5 PRESET 4: 2 WAY ACTIVE FRONT + REAR + SUBWOOFER ........................................................................ 20
5.4.6 PRESET 5: 3 WAY ACTIVE FRONT + REAR + EXTERNAL AMPLIFIED SUB .............................................21
5.4.7 PRESET 6: 2 WAY ACTIVE FRONT + REAR + EXTERNAL AMPLIFIED SUB .............................................22
5.4.8 PRESET 7:
2 WAY ACTIVE FRONT + REAR + 2 WAY CENTER CHANNEL + EXTERNAL AMPLIFIED SUB ... 23
5.5 PERSONAL COMPUTER AND DIGITAL REMOTE CONTROL (DRC). .....................................................................24
6. GUIDE FOR INSTALLING/UNINSTALLING AP F8.9 bit SOFTWARE AND DRIVERS .................................................25
6.1 GUIDED PROCEDURE FOR PC SOFTWARE INSTALLATION .................................................................................. 25
6.2 GUIDED PROCEDURE FOR DRIVER INSTALLATION ...............................................................................................27
6.3 UNINSTALLING AP F8.9 bit SOFTWARE ....................................................................................................................28
7. HOW TO SET UP AP F8.9 bit WITH A PC ...........................................................................................................................29
7.1 OFFLINE MODE ................................................................................................................................................................ 29
7.2 TARGET MODE ................................................................................................................................................................30
7.3 ADJUSTING ACOUSTIC REPRODUCTION .................................................................................................................36
7.3.1 DEVICE INFO. ........................................................................................................................................................ 36
7.3.2 FILE MAIN MENU.................................................................................................................................................37
7.3.3 MEMORIES MAIN MENU ....................................................................................................................................37
7.3.4 SETTINGS MAIN MENU .....................................................................................................................................38
7.3.5 DEVICE MAIN MENU ........................................................................................................................................... 41
7.3.6 HELP MAIN MENU ..............................................................................................................................................42
7.3.7 SELECTED INPUT ................................................................................................................................................42
7.3.8 CHANNEL MAP ....................................................................................................................................................42
7.3.9 SELECT CHANNEL ..............................................................................................................................................43
7.3.10 FILTER SETTINGS................................................................................................................................................43
7.3.11 SET DISTANCE AND DELAY ..............................................................................................................................45
7.3.12 PARAMETRIC EQUALIZER .................................................................................................................................48
7.3.13 OUTPUT LEVEL ....................................................................................................................................................49
7.3.14 MEMORY ...............................................................................................................................................................49
7.3.15 STATUS BAR .........................................................................................................................................................49
8. TROUBLESHOOTING ...............................................................................................................................................................50
8.1 SYNCHRONIZATION WITH A PC .................................................................................................................................. 51
8.2 BACKGROUND NOISE ....................................................................................................................................................52
8.3 FIRMWARE UPGRADE....................................................................................................................................................53
9. ACCESSORIES ..........................................................................................................................................................................53
9.1 DRC DIGITAL REMOTE CONTROL ...............................................................................................................................53
9.1.1 DRC MP .................................................................................................................................................................53
9.1.2 DRC AB ..................................................................................................................................................................53
9.2 SPM4 (Stereo Passive Mixer 4 Ch) ..............................................................................................................................53
9.3 OP 1.5 TOSLINK OPTICAL CABLE 1,5 m / 59.05 in. .................................................................................................54
9.4 OP 4.5 TOSLINK OPTICAL CABLE 4,5 m / 177.16 in................................................................................................54
9.5 STA - F/F SOCKET TOSLINK ADAPTER.. ...................................................................................................................54
10. TECHNICAL SPECIFICATIONS .............................................................................................................................................55
3
AP F8.9 bit /
USER’S MANUAL
1. PRODUCT DESCRIPTION / PRECAUTIONS
2. PACKAGE CONTENTS
- 2 - 30 A replacement fuse:
- 1.8 m USB cable:
- 2.5 mm hex key:
- 4 - 4.2 x 50 mm self-tapping, cross head mounting screws:
- AP F8.9 bit amplifier
- CD ROM containing:
AP F8.9 bit Software
This owner’s manual (.pdf)
Audio Test Tracks
30
A
30
A
AP F8.9 bit is a 9-channel amplifier with 8 amplified channels settable in bridge mode; it also features a 32 bit,
147 MHz clock speed, 24 bit AD/DA converter digital sound processor (DSP), essential to maximize the acoustic
performance of your car audio system.
It can be interfaced with any factory system, even on cars with built-in audio processors, since with the de-equalization
function, AP F8.9 bit will send back a linear signal.
It features 13 signal inputs, 6 Hi-Level, 6 Pre-In and 1 S/PDIF optical digital and provides 8 amplified power outputs
and 1 pre-amplified that is optimized to drive a subwoofer.
Each output channel provides: graphically adjustable parametric equalization group, 68-frequency steps electronic
crossover and BUTTERWORTH or LINKWITZ filters with 6-24 dB slopes and a digital time delay line.
The user can make adjustments that allow him or her to interact with the AP F8.9 bit through the DRC MP remote
control device.
WARNING: 1. A PC provided with Windows Vista, Windows 7 or Windows 8 operating system, 1.5 GHz minimum processor
speed, 2 GB RAM minimum memory and a 1024 x 600 pixels minimum resolution graphics card as well as at
least 1 GB of available hard-disk space are required to install the software and setup the product.
2. Before connecting the product, carefully read this manual. Improper connections may cause damage to AP F8.9 bit
or to the speakers in your car audio system.
- Multipolar cable, Input Speakers IN:
- Multipolar cable, Input Pre-IN:
- Multipolar cable, Rem/Control:
- Multipolar cable Speakers OUT:
IN 1
IN 2
IN 3
IN 4
IN 5
IN 6
IN 6
IN 5
IN 4
IN 3
IN 2
IN 1
OUT 8
OUT 7
OUT 6
OUT 5
OUT 4
OUT 3
OUT 2
OUT 1
1/2
