Side 1/233

Order No: PAPAMY2001019CE

Indoor Unit Outdoor Unit

CS-TZ20WKEW

CS-TZ25WKEW

CS-TZ35WKEW

CS-TZ42WKEW

CS-TZ50WKEW

CS-TZ60WKEW

CS-TZ71WKEW

CS-RZ20WKEW

CS-RZ25WKEW

CS-RZ35WKEW

CS-RZ50WKEW

CU-TZ20WKE

CU-TZ25WKE

CU-TZ35WKE

CU-TZ42WKE

CU-TZ50WKE

CU-TZ60WKE

CU-TZ71WKE

CU-RZ20WKE

CU-RZ25WKE

CU-RZ35WKE

CU-RZ50WKE

Destination

Europe

Turkey

Please file and use this manual together with the service manual for Model No. CU-2Z35TBE, CU-2Z41TBE, CU-2Z50TBE,

CU-3Z52TBE, CU-3Z68TBE, CU-4Z68TBE, CU-4Z80TBE, CU-5Z90TBE, CU-2TZ41TBE, CU-2TZ50TBE, CU-3TZ52TBE,

Order No. PAPAMY1702035CE, PAPAMY1703049CE, PAPAMY1710082CE, PAPAMY1802045CE, PAPAMY1802091CE.

WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.

Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service

or repair the products dealt with in this service information by anyone else could result in serious injury or death.

PRECAUTION OF LOW TEMPERATURE

In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.

CAUTION

R32 REFRIGERANT

– This Air Conditioner contains and operates with refrigerant R32.

THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.

Refer to National, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation,

maintenance and/or service of this product.

R32

REFRIGERANT

R32

REFRIGERANT

IMPORTANT SAFETY NOTICE

There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic

Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced

with manufacturer’s specified

parts to prevent shock, fire or other hazards. Do not modify the original design without permission of

manufacturer.

CAUTION

Before performing any of the electrical installation works, please verify on which of the intended connection use. Generally

there are 2 types of indoor-outdoor connections:

○

Single Connection (Single Indoor Unit connects with Single Outdoor Unit)

○

Multiple Connection (Multiple Indoor Unit connect with Single Outdoor Unit)

Both connections have different connecting methods. Any mismatch connections will result in malfunctions.

The following illustration demonstrates the correct electrical works for both type.

○

(Single Connection)

○

(Multiple Connection)

32S1

Colour of wires (connection cable)

Terminals on the indoor unit

Terminals on the outdoor unit

L 1 N

(Power supply cord)

Terminals on the isolating devices

(Disconnecting means)

(L) (N)

32S1

Colour of wires (connection cable)

Terminals on the indoor unit

Terminals on the outdoor unit

(Power supply cord)

Terminals on the isolating devices

(Disconnecting means)

123

L 1 N S1

Connection for multi inverter model

(Outdoor power supply)

Please refer to the provided Installation Instructions for the detailed procedures for connecting cables to Indoor Unit.

TABLE OF CONTENTS

PAGE PAGE

1. Safety Precautions ............................................. 5

2. Precaution for Using R32 Refrigerant .............. 8

3. Specifications ................................................... 12

4. Features ............................................................ 33

5. Location of Controls and Components .......... 34

5.1 Indoor Unit .................................................. 34

5.2 Outdoor Unit ............................................... 34

5.3 Remote Control .......................................... 35

6. Dimensions ....................................................... 36

6.1 Indoor Unit .................................................. 36

6.2 Outdoor Unit ............................................... 38

7. Refrigeration Cycle Diagram ........................... 40

7.1 CS-TZ20WKEW CU-TZ20WKE

CS-TZ25WKEW CU-TZ25WKE

CS-TZ35WKEW CU-TZ35WKE

CS-TZ42WKEW CU-TZ42WKE

CS-RZ20WKEW CU-RZ20WKE

CS-RZ25WKEW CU-RZ25WKE

CS-RZ35WKEW CU-RZ35WKE ............... 40

7.2 CS-TZ50WKEW CU-TZ50WKE

CS-TZ60WKEW CU-TZ60WKE

CS-RZ50WKEW CU-RZ50WKE ............... 41

7.3 CS-TZ71WKEW CU-TZ71WKE ................ 42

8. Block Diagram .................................................. 43

8.1 Indoor Unit .................................................. 43

8.2 Outdoor Unit ............................................... 44

9. Wiring Connection Diagram ............................ 46

9.1 Indoor Unit .................................................. 46

9.2 Outdoor Unit ............................................... 48

10. Electronic Circuit Diagram .............................. 50

10.1 Indoor Unit .................................................. 50

10.2 Outdoor Unit ............................................... 52

11. Printed Circuit Board ....................................... 54

11.1 Indoor Unit .................................................. 54

11.2 Outdoor Unit ............................................... 58

12. Installation Instruction ..................................... 61

12.1 Select the Best Location ............................ 61

12.2 Indoor Unit .................................................. 63

12.3 Outdoor Unit ............................................... 71

13. Installation and Servicing Air Conditioner

using R32 .......................................................... 75

13.1 About R32 Refrigerant ............................... 75

13.2 Characteristics of R32 Refrigerant ............. 75

13.3 Refrigerant piping installation • Tools used

in services .................................................. 77

13.4 New installation, Relocation,

Repairing of Refrigerant Cycle System

The Procedures .......................................... 81

13.5 Piping installation of R32 ............................ 82

13.6 Installation, Relocation, and Service .......... 83

13.7 Repairing of refrigerant cycle /

Brazing point .............................................. 87

13.8 <Reference> Analysis method for no error

code, no cooling / no warming ................... 93

14. Operation Control ............................................. 95

14.1 Basic Function ............................................ 95

14.2 Indoor Fan Motor Operation ....................... 96

14.3 Outdoor Fan Motor Operation .................... 97

14.4 Airflow Direction ......................................... 98

14.5 Timer Control ............................................ 101

14.6 Sleep Mode Operation ............................. 102

14.7 Auto Restart Control ................................. 103

14.8 Indication Panel ........................................ 103

14.9 Quiet Operation (Cooling Mode/Cooling

Area of Dry Mode) .................................... 103

14.10 Quiet Operation (Heating) ........................ 104

14.11 Powerful Mode Operation ........................ 104

14.12 Wireless LAN Control ............................... 104

15. Operation Control

(For Multi Split Connection) .......................... 107

15.1 Cooling operation ..................................... 107

15.2 Soft Dry Operation .................................... 107

15.3 Heating Operation .................................... 107

15.4 Automatic Operation ................................ 108

15.5 Indoor Fan Motor Operation ..................... 108

15.6 Powerful Mode Operation ........................ 108

15.7 Auto Restart Control ................................. 108

15.8 Indication Panel ........................................ 108

16. Protection Control .......................................... 109

16.1 Protection Control for All Operations ........ 109

16.2 Protection Control for Cooling & Soft Dry

Operation .................................................. 111

16.3 Protection Control for Heating

Operation .................................................. 112

17. Servicing Mode ............................................... 114

17.1 Auto OFF/ON Button ................................ 114

17.2 Heat Only Operation ................................ 115

17.3 Remote Control Button ............................. 117

18. Troubleshooting Guide .................................. 124

18.1 Refrigeration Cycle System ...................... 124

18.2 Breakdown Self Diagnosis Function ........ 126

18.3 Error Codes Table .................................... 127

18.4 Self-diagnosis Method .............................. 129

19. Disassembly and Assembly Instructions .... 157

19.1 CS-TZ20WKEW CS-TZ25WKEW

CS-TZ35WKEW CS-TZ42WKEW

CS-TZ50WKEW CS-RZ20WKEW

CS-RZ25WKEW CS-RZ35WKEW

CS-RZ50WKEW ....................................... 157

19.2 CS-TZ60WKEW CS-TZ71WKEW ........... 162

19.3 To Replace Wireless LAN Module

(Network Adapter) .................................... 167

19.4 Outdoor Electronic Controller Removal

Procedure ................................................. 168

19.5 To Set Panasonic Comfort Cloud App.

After Replace Main Printed Circuit Board

and Wireless LAN Module ......................... 171

Produkspesifikasjoner

Merke:	Panasonic
Kategori:	luftkondisjonering
Modell:	CS-RZ35WKEW
Bruksanvisning:	Ja
Kjølemedium:	R32
Wi-Fi:	Ja
Årlig energiforbruk (oppvarming) (gjennomsnittlig fyringssesong):	852 kWh
Luftfilter:	Ja
Filtertype:	Polyetylentereftalat (PET)
Energiforbruk per time (kjøling):	- kWh
Energiforbruk per time (oppvarming):	- kWh
Dybde innendørsenhet:	209 mm
Høyde innendørsenhet:	290 mm
Antall innendørsenheter:	1
Antall utendørsenheter:	1
Energieffektivitetsskala:	A+++ til D
Produktfarge:	Hvit
Fjernkontroll medfølger:	Ja
Modell/Type:	Delt System (AC)
Kjølekapasitet i watt (nominell):	3500 W
Fjernstøtte via smarttelefon:	Ja
Inverteringsteknologi:	Ja
Nedkjølingskapasitet i watt (maks.):	3900 W
Kjøling medium vekt:	700 g
Fjerndrevet:	Ja
Klimaanleggets funksjoner:	Cooling, Heating
Nedkjølingskapasitet (maks.):	13300 BTU/t
Kjøleenergieffektivitet (EER, W/W):	3.5
Oppvarmingskapasitet i watt (maks.):	5100 W
Årlig energiforbruk (nedkjøling):	198 kWh
Nedkjølingskapasitet (min.):	2900 BTU/t
Varmekapasitet i watt (nominell) (Varmeste fyringssesong):	- W
Varmekapasitet i watt (nominell) (Gjennomsnittlig fyringssesong):	4000 W
Varmekapasitet i watt (nominell) (Kalde fyringssesong):	- W
Design belastning (kjøling):	3.5 kW
Design belastning (varming) (Varm fyrings sesong):	- kW
Design belastning (varming) (Gjennomsnitt fyrings sesong):	2.8 kW
Design belastning (varming) (Kald fyrings sesong):	- kW
Årlig energiforbruk (oppvarming) (Varmeste fyringssesong):	375 kWh
Årlig energiforbruk (oppvarming) (Kalde fyringssesong):	- kWh
Støynivå på innendørsenhet (høy hastighet):	42 dB
Bredde innendørsenhet:	779 mm
Innendørsenhetens vekt:	8000 g
Innendørs enhetstype:	Vegg.monterbar
Støynivå på utendørsenhet:	62 dB
Bredde utendørsenhet:	780 mm
Dybde utendørsenhet:	289 mm
Høyde utendørsenhet:	542 mm
Oppvarmingskapasitet i watt (min.):	800 W
Utendørsenhetens vekt:	31000 g
Multisplitt:	Nei
Sesongbasert effektivitetsrangering (nedkjøling) (SEER):	6.2
Sesong-virkningsgrad (oppvarming) (SCOP) (Gjennomsnittlig i fyringssesongen ):	4.6
Oppvarmingsenergieffektivitet (COP, W/W):	3.81
Nedkjølingskapasitet i watt (min.):	850 W
Nedkjølingskapasitet (nominell):	11900 BTU/t
Oppvarmingskapasitet (nominell):	13600 BTU/t
Oppvarmingskapasitet (min.):	2730 BTU/t
Oppvarmingskapasitet (maks.):	17400 BTU/t
Automatisk vifte:	Ja
Diameter på dreneringsslange:	16 mm
Gasslangediameter:	9.52 mm
Slangelengde (maks):	15 m
Slangelengde (min):	3 m
Væskeslangediameter:	6.35 mm
Type delt system:	Mono split
Energieffektivitetsklasse (nedkjøling):	A++
Innendørsenhetens støynivå:	58 dB
Støynivå på innendørsenhet (lav hastighet):	33 dB
Utendørsenhetens støynivå:	47 dB
