Side 1/28
ALSO AVAILABLE:
FIREPROOF BACKBOXES
CS SERIES
OWNERS MANUAL
Paradigm Electronics Inc., 205 Annagem Boulevard, Mississauga, ON L5T 2V1 T: (905) 564-1994 F: (905) 564-8726
HIGH-DEFINITION SOUND
™
100313
1
FIREPROOF BACKBOXES
Paradigm in-wall and in-ceiling applications can now be spec’d for multi-dwelling
unit applications.
Paradigm backboxes meet the following:
• ‘One-Hour Fire-Rating’ requirements
• ‘For Use in Air Handling Spaces’ requirements
Paradigm backboxes will contain fire, gas, smoke and heat within the enclosure for
up to one hour.
Paradigm backboxes also meet the following codes:
ASTM E119-98 Vertical
ASTM E119-98 Horizontal
UBC 7-1
UL 2043
CAN/ULC S101-M89
Backbox Features:
• Corrosion-resistant metal;
• Insulated lining;
• 10 db of acoustic isolation between room boundaries;
• Integrated safety tab on the back of the cabinet accommodates installer-supplied
safety cable;
• Standard top-surface 3/8˝ knockouts for conduit set-screw connector. Positioning of
knockouts allows for vertical or horizontal installs;
• Pre-drilled mounting holes surround flange for easy installation;
• All boxes fit 12˝, 16˝ and 24˝ stud bays.
See your dealer for a firebox to fit your model.
TABLE OF CONTENTS
Fireproof Backboxes ..................1
Your New Speakers
..................2
How To Avoid Speaker Damage
.......2
Your Listening Room
.................2
Speaker Assembly Parts List
..........2
Speaker Placement Guidelines
........3
Color-Match Painting
.................5
Installation
......................... . 5
Speaker Placement (pictorial)
......... . 7
Speaker Installation and
Connection (pictorial)
................ . 9
Speaker Connection
................. 11
Troubleshooting Guide
............... 11
Limited Warranty
.................... 12
2
YOUR NEW SPEAKERS
Although CS Series in-wall/in-ceiling speakers sound great out of the carton, they will sound
even better once they are broken in. Operate them for several hours before you listen critically.
High-frequency drivers use ferro-fluid that can thicken at temperatures below 10° C (50° F).
If your speakers have been transported or stored in the cold, let them warm to room
temperature before use.
Clean speaker housing with a soft, damp cloth. Do not use a strong or abrasive cleaner or
get any part of the speaker wet.
HOW TO AVOID SPEAKER DAMAGE
Use an appropriate amplifier. At high volumes, a very powerful amplifier can overdrive your
speakers and damage them. On the other hand, if your amplifier isn’t powerful enough, it can
produce clipping distortion that can easily damage high-frequency drivers. (See your dealer.)
Don’t be fooled by your amplifier’s volume control. It adjusts listening level—it does not
indicate power output. If your speakers begin to sound harsh or grating, or if you hear the
bass breaking up, turn the volume down immediately or you will damage your speakers!
This type of damage constitutes abuse and is not covered by warranty!
Tone controls and equalizers can demand even more power from an amplifier, lowering the
point at which it produces clipping distortion. Use them sparingly, if at all, and do not use
them when listening at loud levels.
YOUR LISTENING ROOM
The CS Series in-wall/in-ceiling speakers are suitable for use in a wide variety of listening
environments. Note however, that room construction, dimensions and furnishings will all
play a part in the quality of sound you ultimately achieve. The extra care taken in installation
will result in greater listening enjoyment. Try to follow these guidelines:
a) Strong, rigid walls and ceilings are preferred for best bass balance. For even better
results, add cross-braces at about 12˝ (30 cm) above and below (either side) the
speaker to further increase rigidity.
b) Midrange and high frequencies are affected by room furnishings. For best sound, your
listening room should contain an average amount of curtains, carpets, sofas, etc.
SPEAKER ASSEMBLY PARTS LIST (one speaker)
• 1 in-wall/in-ceiling speaker complete with attached mounting clamps and screws, wire tie
• 1 mounting template
