Side 1/44
© 2017 Phoenix Gold • www.phoenixgold.com
Features CaractéristiquesCaracterísticas:
• All models are full range capable Class-D
Topology
• Monoblocks Master/Slave strappable for
huge power
• Monoblocks Master/Slave linkable for multi-
amp Setups
• Bridgeable channels
• Double tier power supplies with OTM Onboard
Thermal Management
• Remote bass and phase controller with Bass
Shift
®
(RBPC)
• Switchable balanced or unbalanced inputs
• Auto-turn on circuit (defeatable)
• Tri-lightLEDamplierstatusindicators
• Short circuit, thermal and voltage protection
• Front mount controls and connections
• RCA pass-through outputs on Monoblocks
• RMD ready – Remote monitoring display port
(RMD sold separately)
• Todos los modelos son topología Clase-D de
gama completa
• Monoblocks Maestro/Esclavo con correa para
una Gran Potencia
• Monoblocks Maestro/Esclavo vinculables para
conguracionesdeMulti-Amplicadores
• Canales insertables
• Fuentes de alimentación de dos niveles
• Control remoto de bajos y regulador de fase
con Bass Shift® (RBPC)
• Entradas conmutables balanceadas o no
balanceadas
• Circuito de encendido automático
(desbloqueable)
• Indicadoresdeestadodelamplicadorde
tres luces LED
• Protección contra cortocircuitos, térmicos y
de voltaje
• Controles y conexiones de montaje frontal
• “Pass-through” salidas RCA en Monoblocks
• VMR listo – Puerto de visualización de
monitoreo remoto (El VMR se vende por
separado)
• Tous les modèles ont une topologie de classe
D avec une gamme complète
• Monoblocs originaux/esclaves pouvant être
reliés à un courant puissant
• Monoblocs originaux /esclaves pouvant
être reliés à une installation à plusieurs
amplicateurs
• Pontable à canaux
• Alimentation à deux étages
• Contrôleur de phase et de basse à distance
avec Bass Shift®(RBPC)
• Entrées symétriques ou asymétriques
commutables
• Circuit de mise en marche automatique
(désactivable)
• Voyants DEL à trois lumières de l’état de
l’amplicateur
• Protection thermique et contre les surtensions
et les courts-circuits
• Commandes et raccords à montage frontal
• Sorties intercommunication RCA “pass-
through” en Monoblocs
• Prêt RMD – Port d’écran de contrôle à
distance (RMD vendu séparément)
Models: SX2 400.2, SX2 800.4, SX2 600.1, SX2 1200.1, SX2 1200.6
Amplifier
Manual
Manual del Amplificador
Manuel de l’amplificateur
Amplifier Owner’s Manual
© 2017 Phoenix Gold • www.phoenixgold.com
SX2 400.2 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 2
1Ω: N/A
2Ω: 200Wx2
4Ω: 100Wx2
4Ω:Bridged 400Wx1
TotalRMSPower(Sumofratedpower): 400W
Bridgeable: Yes
Crossover Control, Butterworth: FLAT/HP/LP
55Hz - 4kHz @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
®
: N/A
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8V Unbalanced
600mV-16V Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 76.5dB
Frequency Response: 10Hz - 39kHz @ +/-3.0dB
Efciency(Average): 88%
SX2 800.4 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 4
1Ω: N/A
2Ω: 200Wx4
4Ω: 150Wx4
4Ω:Bridged 400Wx2
TotalRMSPower(Sumofratedpower): 800W
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FLAT/HP/LP/BP
55Hz - 4kHz @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
®
: Yes
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 81.4dB
Frequency Response: 10Hz- 39kHz @ +/-3.0dB
Efciency(Average): 88%
IMPORTANT:Apowerbirthcerticateisincludedforeachamplier.SX2ampliersare
conservatively rated and will exceed their RMS power rating shown here. All RMS power
ratingsandmeasurementsareat14.4voltswithnomorethan1%THD.
Auto-Turn On: Yes
Damping Factor: Greater than 250
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 40A
Average Current Draw @ 14.4v Music: 9A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 10.5”x8.5”x2”
267mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 50A
Average Current Draw @ 14.4v Music: 16A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 15.25”x8.5”x2”
387mm x 216mm x 51mm
SPECIFICATIONS
© 2017 Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
SX2 600.1 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 1
1Ω: 600Wx1
2Ω: 450Wx1
4Ω: 300Wx1
TotalRMSPower(Sumofratedpower): 600W
Bridgeable: N/A
Crossover Control, Linkwitz-Riley: HP 10Hz - 120Hz (subsonic)
FLAT/LP 40Hz - 240Hz @ 24dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
®
: Yes
40Hz EQ 0-6dB boost @ 40Hz: Yes
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: 2 Channel RCA
Signal to Noise (@ CEA Standard): 85.9dB
Frequency Response: 10Hz - 250Hz @ +/-6.0dB
10Hz -39kHz -3dB LP BYPASSED
Efciency(Average): 85%
SX2 1200.1 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 1
1Ω: 1200Wx1
2Ω: 900Wx1
4Ω: 600Wx1
TotalRMSPower(Sumofratedpower): 1200W
Bridgeable: N/A
Crossover Control, Linkwitz-Riley: HP 10Hz - 120Hz (subsonic)
LP 40Hz - 240Hz @ 24dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
®
: Yes
40Hz EQ 0-6dB boost @ 40Hz: Yes
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: 2 Channel RCA
Signal to Noise (@ CEA Standard): 86.3dB
Frequency Response: 11Hz - 250Hz @ +/-6.0dB
10Hz -39kHz +/-3dB LP BYPASSED
Efciency(Average): 85%
SX2 1200.6 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 6
1Ω: 1-4N/A,5-6250Wx2
2Ω: 200Wx6
4Ω: 150Wx6
Bridged4Ω: 300Wx2
Bridged2Ω: 1-4N/A,5+6500Wx1
TotalRMSPower(Sumofratedpower): 1300W
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FLAT/HP/LP/BP
55Hz - 4kHz @ 12dB/Oct
Channels 5/6 only: HP 10Hz - 120Hz (subsonic)
LP 45Hz - 1K @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
®
: Yes
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 81.4dB
Frequency Response: 10Hz- 39kHz @ +/-3.0dB
Efciency(Average): 88%
Auto-Turn On: Yes
Damping Factor: Greater than 200
MASTER/SLAVECapable: Yes-1200Wx1@2ΩStrapped
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 60A
Average Current Draw @ 14.4v Music: 15A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 13.25”x8.5”x2”
337mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
MASTER/SLAVECapable: Yes-2400Wx1@2ΩStrapped
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 80A
Average Current Draw @ 14.4v Music: 26A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 16.75”x8.5”x2”
425mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 70A
Average Current Draw @ 14.4v Music: 24A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 19.25”x8.5”x2”
489mm x 216mm x 51mm
SPECIFICATIONS
Produkspesifikasjoner
| Merke: | Phoenix Gold |
| Kategori: | Mottaker |
| Modell: | SX2 1200.1 |
Trenger du hjelp?
Hvis du trenger hjelp med Phoenix Gold SX2 1200.1 still et spørsmål nedenfor, og andre brukere vil svare deg
Mottaker Phoenix Gold Manualer
26 August 2025
26 August 2025
27 Januar 2025
27 Januar 2025
27 Januar 2025
18 Januar 2025
18 Januar 2025
18 Januar 2025
18 Januar 2025
17 Januar 2025
Mottaker Manualer
- Mottaker Bosch
- Mottaker Power Dynamics
- Mottaker Vonyx
- Mottaker Akg
- Mottaker Jensen
- Mottaker Hartke
- Mottaker Philips
- Mottaker Goobay
- Mottaker Avantree
- Mottaker Godox
- Mottaker Cayin
- Mottaker Meridian
- Mottaker Teufel
- Mottaker Fender
- Mottaker Axton
- Mottaker Kogan
- Mottaker DJI
- Mottaker McIntosh
- Mottaker Behringer
- Mottaker Sony
- Mottaker Pro-Ject
- Mottaker Yamaha
- Mottaker Morel
- Mottaker Extron
- Mottaker Lindy
- Mottaker Pioneer
- Mottaker NuPrime
- Mottaker Ecler
- Mottaker AudioControl
- Mottaker Audac
- Mottaker Rotel
- Mottaker Audio-Technica
- Mottaker Toa
- Mottaker Marantz
- Mottaker Rega
- Mottaker Vox
- Mottaker Pyle
- Mottaker Shure
- Mottaker Roland
- Mottaker NAD
- Mottaker Wet Sounds
- Mottaker JVC
- Mottaker VMV
- Mottaker S.M.S.L
- Mottaker Kicker
- Mottaker Auna
- Mottaker OSD Audio
- Mottaker DataVideo
- Mottaker Audizio
- Mottaker Bluesound
- Mottaker Blackstar
- Mottaker Hertz
- Mottaker Kenwood
- Mottaker Cambridge
- Mottaker MB Quart
- Mottaker Aplic
- Mottaker CSL
- Mottaker NUVO
- Mottaker IFi Audio
- Mottaker Tripp Lite
- Mottaker Henry Engineering
- Mottaker Block
- Mottaker Smart-AVI
- Mottaker Advance
- Mottaker Artsound
- Mottaker Denon
- Mottaker Marshall
- Mottaker Yorkville
- Mottaker Valcom
- Mottaker Mosconi
- Mottaker JBL
- Mottaker Infinity
- Mottaker Helix
- Mottaker Soundstream
- Mottaker Klipsch
- Mottaker PAC
- Mottaker Bellari
- Mottaker Rolls
- Mottaker Ground Zero
- Mottaker Karma
- Mottaker Glemm
- Mottaker EA
- Mottaker Match
- Mottaker Renkforce
- Mottaker Scansonic
- Mottaker SPL
- Mottaker Audiotec Fischer
- Mottaker Crunch
- Mottaker QSC
- Mottaker A-NeuVideo
- Mottaker Atlona
- Mottaker Classé
- Mottaker FoneStar
- Mottaker Palmer
- Mottaker Monitor Audio
- Mottaker Peavey
- Mottaker Crown
- Mottaker Fosi Audio
- Mottaker Graupner
- Mottaker Antelope Audio
- Mottaker Vaddio
- Mottaker Stinger
- Mottaker ESX
- Mottaker Omnitronic
- Mottaker Rocstor
- Mottaker Russound
- Mottaker MEE Audio
- Mottaker Monacor
- Mottaker GigaBlue
- Mottaker Mx Onda
- Mottaker Black Hydra
- Mottaker Electro-Voice
- Mottaker Wharfedale
- Mottaker Boss
- Mottaker JL Audio
- Mottaker Shanling
- Mottaker Atlas Sound
- Mottaker Comica
- Mottaker Ashly
- Mottaker MuxLab
- Mottaker Audiolab
- Mottaker Lectrosonics
- Mottaker Memphis Audio
- Mottaker Focal
- Mottaker Alpine
- Mottaker Evolution
- Mottaker AVM
- Mottaker Primare
- Mottaker Elektrobock
- Mottaker PureLink
- Mottaker Kramer
- Mottaker ATen
- Mottaker Blustream
- Mottaker Mtx Audio
- Mottaker Yaesu
- Mottaker Musical Fidelity
- Mottaker RCF
- Mottaker Vimar
- Mottaker Bogen
- Mottaker RDL
- Mottaker Harman Kardon
- Mottaker Dynacord
- Mottaker Ferguson
- Mottaker DAP Audio
- Mottaker REL Acoustics
- Mottaker Inovonics
- Mottaker KanexPro
- Mottaker BZBGear
- Mottaker Bresser
- Mottaker InLine
- Mottaker Ram Audio
- Mottaker Gefen
- Mottaker Alecto
- Mottaker Strong
- Mottaker Vincent
- Mottaker Alfatron
- Mottaker HiFi ROSE
- Mottaker Intelix
- Mottaker Comprehensive
- Mottaker Deaf Bonce
- Mottaker Fiio
- Mottaker FBT
- Mottaker Lab Gruppen
- Mottaker GlobalSat
- Mottaker AVMATRIX
- Mottaker Kathrein
- Mottaker Imperial
- Mottaker Hifonics
- Mottaker Hotone
- Mottaker Phonic
- Mottaker AudioSource
- Mottaker Taga Harmony
- Mottaker SoundTube
- Mottaker James
- Mottaker Geemarc
- Mottaker Devialet
- Mottaker ButtKicker
- Mottaker Antelope
- Mottaker Futaba
- Mottaker Neumann
- Mottaker Crest Audio
- Mottaker Mooer
- Mottaker Rexing
- Mottaker Marshall Electronics
- Mottaker Atoll
- Mottaker August
- Mottaker Inter-M
- Mottaker Esoteric
- Mottaker Alto
- Mottaker Konig & Meyer
- Mottaker Lumantek
- Mottaker Aguilar
- Mottaker Mark Levinson
- Mottaker Selfsat
- Mottaker Proel
- Mottaker Audibax
- Mottaker Line 6
- Mottaker Luxman
- Mottaker Sound Ordnance
- Mottaker Wavtech
- Mottaker Dual
- Mottaker Parasound
- Mottaker Benchmark
- Mottaker Koda
- Mottaker Technical Pro
- Mottaker Naim
- Mottaker Anthem
- Mottaker Audison
- Mottaker Loxjie
- Mottaker Clare Controls
- Mottaker Edwards Signaling
- Mottaker Iriver
- Mottaker Hegel
- Mottaker PTN-electronics
- Mottaker Datapath
- Mottaker Sunfire
- Mottaker DLS
- Mottaker Triax
- Mottaker Xtrend
- Mottaker Nubert
- Mottaker VigilLink
- Mottaker Harper
- Mottaker SmartSystem
- Mottaker DARTS
- Mottaker ETON
- Mottaker Elipson
- Mottaker Streacom
- Mottaker Phonocar
- Mottaker Diamond Audio
- Mottaker Rockville
- Mottaker CYP
- Mottaker DS18
- Mottaker Coastal Source
- Mottaker Swissonic
Nyeste Mottaker Manualer
25 August 2025
25 August 2025
25 August 2025
25 August 2025
25 August 2025
24 August 2025
24 August 2025
24 August 2025
24 August 2025
23 August 2025
