Above-Ground
Pool Automation Control
PAGAUT
Owner’s Manual
English | Français | Español
WARNING
FOR YOUR SAFETY - This product must be installed by a qualied pool professional or personnel who are
knowledgeable with the standards and code requirements for above ground pool equipment. The maintainer
must be a qualied pool professional or personnel with sucient experience in pool equipment installation and
maintenance so that all of the instructions in this manual can be followed exactly.
Improper installation and/or operation may result in death, serious injury or property damage. DO NOT MODIFY
THIS EQUIPMENT.
Before installing this product, read and follow all warning notices and instructions that accompany
this product. Failure to follow warning notices and instructions may result in death, serious injury
or property damage. Consult Polaris customer service at 1-800-822-7933 for assistance. Improper
installation and/or operation may void the warranty.
ENGLISH
Polaris
®
PAC
™
Pool Automation Control
|
Owner’s Manual
Page 2
Table of Contents
Section 1. Important Safety Instructions ................................................................................................... 3
Section 2. System Overview .......................................................................................................................5
2.1 Package Contents..................................................................................................................................... 5
2.2 Electrical Specications ............................................................................................................................ 5
2.3 Materials and Tools ................................................................................................................................... 5
Section 3. Install Controller Box ................................................................................................................5
3.1 Mount the Controller Enclosure ................................................................................................................ 5
3.2 Bonding the Power Center ........................................................................................................................ 6
Section 4. High Voltage Plug In ..................................................................................................................6
4.1 Plug In Assignment ................................................................................................................................... 6
Section 5. Low Voltage Wiring ....................................................................................................................6
5.1 Wire the Temperature Sensors ................................................................................................................. 6
5.2 Install the Water Temperature Sensor....................................................................................................... 6
5.3 Install a Solar Sensor (if applicable) ......................................................................................................... 7
5.4 Install Additional Low Voltage Equipment (i.e., Heater Connection) ......................................................... 7
5.5 Install iAquaLink
™
(if applicable) ............................................................................................................... 7
5.6 Mount the iAquaLink Device ..................................................................................................................... 7
5.7 Wire the iAquaLink Device ........................................................................................................................ 7
5.8 Install Jandy Valve
®
Actuators (JVAs) (if applicable) ................................................................................. 7
Section 6. User Interface ............................................................................................................................. 7
6.1 Navigation Buttons .................................................................................................................................... 7
Section 7. Install Settings ...........................................................................................................................8
7.1 Freeze Protect .......................................................................................................................................... 8
7.2 Units .......................................................................................................................................................... 9
7.3 Languages ................................................................................................................................................ 9
7.4 Clear Memory ........................................................................................................................................... 9
7.5 Color Lights ............................................................................................................................................... 9
7.6 Label Auxiliary Functions ........................................................................................................................ 10
7.7 Temp Calibrate ........................................................................................................................................ 10
7.8 Solar Priority (if applicable) ..................................................................................................................... 10
7.9 Assign JVA .............................................................................................................................................. 10
7.10 Diagnostics ..............................................................................................................................................11
Section 8. Main Menu ................................................................................................................................12
8.1 Equipment Status.................................................................................................................................... 12
8.2 Filter Pump .............................................................................................................................................. 12
8.3 Pool Heater On/O ................................................................................................................................. 12
8.4 Turn Aux1, Aux2 or Aux3 On/O ............................................................................................................ 12
8.5 Turn Specic Equipment On/O Manually .............................................................................................. 13
8.6 Turn All Equipment O ............................................................................................................................ 14
Section 9. Pool Only System Menu Flow Diagrams ...............................................................................15
9.1 Main Menu .............................................................................................................................................. 15
9.2 Install Settings Menu............................................................................................................................... 16
Section 10. Glossaries ................................................................................................................................17
10.1 Glossary of Safety Delays and Lockouts ................................................................................................ 17
10.2 Glossary of Alert Messages .................................................................................................................... 17
Section 11. Wiring Diagram ........................................................................................................................18
FCC Regulatory Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation/
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance may void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
