Side 1/5
Part 1
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex Technology, Inc. has made every effort for the accuracy of the content in this
manual. However, Posiflex Technology, Inc. will assume no liability for any technical
inaccuracies or editorial or other errors or omissions contained herein, or for direct,
indirect, incidental, consequential or otherwise damages, including without limitation
loss of data or profits, resulting from furnishing, performance, or use of this material.
This information is provided “as is” and Posiflex Technology, Inc. expressly disclaims
any warranties, expressed, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw or http://www.posiflexusa.com
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex Technology, Inc. will not be responsible for any loss of data
resulting from the use, disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Technology, Inc. 2011
All brand and product names and trademarks are the property of their respective holders.
KP-450 Side Mount
Programmable Keypad
User’s Manual
Rev.:
Original
P/N:
18410900010
Part 2
GENERAL DESCRIPTION
OVERVIEW
KP-450 is 45 keys upgrade kit for Posiflex POS terminal KS-6910TS series.
29 programmable keys with 15 numeric keys (including 1 double key) place a
convenience side mount input devise for pleasant user experience.
INSTALLATION
For KP-450 to install in the KS-6910TS series, please arrange
the KS-6910TS’s main unit on a flat surface and unfasten
these screws which circled in the right picture to release the
cover.
There is a cable which you may find after the cover released
and please pull it out genteelly. Next, connect this cable to the
connector which on the left side of KP-450 as shows in the
right picture.
After connect this cable, please hold the KP-450 and join to
the KS-6910TS main unit and as arrowed in the right
picture.
After match the KP-450, please use the original screws to
fasten the Keypad. Please reserve the cover if there is a
possibility to remove the side mount upgrade kit.
KEYTOP LAYOUT
Keytop Replacement
The keypad in KP-450 is organized into 2 parts: a 4 X 4 numerical keypad area
and a 1 X 4 matrix with a 5 x 5 square programmable keypad areas.
Conversely, this keypad allows some layout alterations by the system
integrator. Besides the standard single key installed, there are double keys and
blank keys for purchase to provide more convenient user interface.
When replacement of keytop is required, it is advisable to use a flattop (minus
sign) screw driver (Do not use the attached key clip for this operation.) to help
getting the key top off gently. Please always first orientate the key tops as
Part 3
below before inserting any keytop into the case of the keypad. Failure to do so
could result in permanent damage not covered in product warranty.
Please always match the latching tab on bottom stem of keytop with the tab in
guiding hole and gently press the key top down till a click sound is heard as
indicated in the pictures below.
Labeling On Keytop
The programmable keypad is provided easy and durable method for reminding
the user of content programmed in each programmable key. First preprint (or
write) in each cell of the attached colored sheet the “name” for each key. Stick
each cell to the corresponding keytop and then put on the transparent key cap
from the accessories. In this way, the labeling will be protected and resistant to
scratch or rubbing.
When re-labeling is required, please use the attached key clip to hook up the
transparent key cap and change the label then re-cap.
KEYPAD PROGRAMMING
The programming of the keys above the numerical keypad in KP-450 is in
general the task of the system integrator and not the average end user. For end
user, please go to the chapter of “OPERATION GUIDE” of this manual
directly.
Utility Installation
In the Posiflex Product Information CD attached with KP-450 or please
download from our web site: http://www.posiflex.com the keypad
programming utility for KP-450.
In the above mentioned subfolder please find a further subfolder “uKBW_xxx”
with “xxx” representing any number of the utility revision. This is a Windows
utility for the KP-450. Execute “uKBW_xxx\SETUP.EXE” to install the
Single key top
Latching tab
Double key top
Tab in the
guide hole
Produkspesifikasjoner
| Merke: | Posiflex |
| Kategori: | Tastatur |
| Modell: | KP-450 |
