Side 1/12
Visit Our Website
SCAN ME
PyleUSA.com
USER GUIDE
PPHP26HD
Dual 5" Portable BT Boombox Speaker
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
Features:
• Dual 5" High-Performance Speakers
• Outdoor-Ready Construction, Rugged Design for Outdoor Durability
• Bluetooth for Wireless Streaming
• Delivers Clear and Immersive Audio with Deep Bass
• 3.5mm Auxiliary Input
• Mic Priority for Clear Vocals
• Echo and Mic Volume Controls for Karaoke
• Built-in Rechargeable Battery with LED Indicator
• Multiple Input Options Including Bluetooth, USB/ Micro SD, 3.5mm Auxiliary
Input, 6.5mm Microphone input, and FM Radio
• User-Friendly Controls for Volume and Playback
• Sturdy Handle for Easy Transportation
• Dynamic LED Ring Lights Synced with Music
• Ideal for Outdoor-Party, Gatherings, and Travel
• Connects to External Audio Devices
• Suitable for Indoor/Outdoor Use
Bluetooth Wireless Streaming:
• Built-in Bluetooth Receiver for Wireless Music Streaming
• Easy and Quick Pairing Setup
• Works with Today's Latest Devices (Smartphones, Tablets, Laptops, Computers, etc.)
• Bluetooth Network Name: PYLEUSA
• Bluetooth Version: 5.0
• Wireless Range: 50 ft.
What's in the Box:
• Portable Boombox Speaker
• TYPE-C Charging Cable
• Remote Control
Technical Specs:
• Construction Material: PP+ABS
• Recommended Power Output: 160W
• RMS Power: 40W
• Sound System: 5" -inches Woofer x 2 + 2“- inch Tweeter
• Impedance: 4 Ohm
• USB Interface Type: 2.0
• Digital Audio File Support: WAV/WMA/APE/FLAC/MP3
• Maximum USB Flash Support: 64G
• Remote Control Battery Operated, Requires AAA x 2 Batteries, (Not included)
• Battery Type: 7.4V/ 4400mAh, 32.56Wh Lithium Battery
• Battery Working Time: 2-8 hours (Vary with Volume)
• Battery Construction Material: 18650 (6) Battery Cell
• Item Weight: 9.2 lbs.
• Power Cable Length: 3.28 ft.
• Power Supply: DC 5V/ 2A
• Product Dimension (L x W x H): 18.7" x 7.3" x 9.8" –inches
California Prop 65 Warning
WARNING:
This product contains “Lead and lead compounds” which is
known to the state of California to cause cancer birth defects
and other reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
Illegal operation may cause personal injury, which could be fatal.
Illegal operation may cause damage to property.
Important Safety Instructions:
1. Read these instructions carefully.
2. Read all warnings
3. Follow all instructions.
4. Do not expose this apparatus to water, corrosive liquids, or gas.
Store the apparatus in a dry and clean place.
5. Do not install the speaker system near windows or any heat sources such as
radiators, heat registers, gas stoves, or other apparatuses that produce heat.
6. Do not place any naked ame sources, such as lit candles, on or near the
apparatus.
7. Clean only with a dry cloth.
8. Do not place objects lled with any kind of liquid on the speakers.
9. To reduce the risk of re or electric shock, do not expose this product to rain
or moisture. Liquids can cause a failure and/or re hazard.
10. Do not insert metal bars, wires, or any other objects into the speaker hole.
11. Protect the power cord from being walked on or pinched, particularly at
plugs and the point where they exit from the apparatus.
12. To reduce the risk of electric shock, do not handle the plug with wet hands.
13. Before moving the speakers, pull out the power adapter and disconnect
from any other equipment.
14. Do not block any ventilation openings of the device, as this will cause a rise
in the internal temperature of the apparatus and potentially damage the
circuit.
15. Do not press the switches or other keys with force.
16. Unplug the power cable immediately if your device emits smoke or acts
abnormally. Seek professional help from your nearest service center.
17. Only use attachments recommended by the manufacturer.
Use of other attachments may be hazardous.
18. Do not throw used batteries in with your household rubbish.
Follow instructions from your local council about safe disposal.
Using the Remote Control
Installing the Batteries
Remove the battery cover from the back of the Remote Control as shown
and insert 2xAAA size batteries ensuring correct polarity.
1. Mute
2. Fm radio
3. 0-9 keys
4. Repeat
5. Tws
6. Play/pause
7. Previous song
8. VoIume+
9. Next song
10. Volume-
11. Record key
12. Mic Priority
13. Record play
14. Mic vol-
15. Mic voI+
16. Wireless BT
17. Bass+
18. Bass-
19. Aux
20. Echo+
21. Echo-
22. USB
23. TrebIe+
24. Treble-
Note for remote:
The remote control should be used within 6m from the device, around 30
degree on the left/right side, pointed directly tow ards the speaker system.
1 2 3
AUX
- +
TWS
FM
REPREC
PRIOR
MIC VOL
BT
BASS
USB
TREBLE ECHO
1
2
3
5
8
9
12
13
15
19
22
20
23
21
24
4
6
7
11
14
16
17
18
10
