Pyle PPHP868ST Bruksanvisning

Pyle Høyttaler PPHP868ST

Les nedenfor 📖 manual på norsk for Pyle PPHP868ST (8 sider) i kategorien Høyttaler. Denne guiden var nyttig for 18 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF
Side 1/8
Visit Our Website
SCAN ME
PyleUSA.com
USER GUIDE
PPHP868ST - PPHP868STBG
Portable BT Speaker System
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
PPHP868ST - PPHP868STBG
HVIN: PPHP868ST / PPHP868STBG
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
Features:
• True Wireless Stereo System
• High-Fidelity Sound with Deep Bass and Clear Highs
• Dual Stereo Speakers for Immersive Audio Experience
• Rugged, Molded Cabinet Design
• 6.5mm Microphone Input
• Multiple Input Options Including Bluetooth, USB/ SD, 6.5mm Microphone input,
and FM Radio
• User-Friendly Controls for Volume, Playback, and Mode Selection
• Built-in Rechargeable Battery with Light Indicator
• Sturdy Handle for Easy Transportation
• Echo, Bass, and Treble Control Function
• Dynamic LED Ring Lights Synced with Music
• Includes Tripod Stand
• Customize Audio Output with Preset Equalizer Settings
• LED Display for Clear Visibility of Settings
• Ideal for Parties, Karaoke Nights, and Outdoor Events
• Bluetooth for Wireless Streaming
• Suitable for Indoor/Outdoor Use
Bluetooth Wireless Streaming:
• Built-in Bluetooth Receiver for Wireless Music Streaming
• Easy and Quick Pairing Setup
• Works with Today's Latest Devices (Smartphones, Tablets, Laptops, Computers, etc.)
• Bluetooth Network Name: PYLEUSA
• Bluetooth Version: 5.0
• Wireless Range: 50 ft.
What's in the Box:
• Portable Bluetooth Speaker
• Power Adapter
• Remote Control
• Tripod Stand
• Speaker Bag ( )for PPHP868STBG model only
Technical Specs:
• Construction Material: ABS + Iron Grill
• Recommended Power Output: 120W
• RMS Power: 30W
• Sound System: 8" -inches Woofer + 1“- inch Tweeter
• Impedance: 4 Ohm
• USB Interface Type: 2.0
• Digital Audio File Support: MP3 / WAV
• Maximum USB Flash Support: 64G
• Remote Control Battery Operated, Requires AAA x 2 Batteries, (Not included)
• Battery Type: 7.4V/ 5400mAh, 39.96Wh Lithium Battery
• Battery Working Time: 2-8 hours (Vary with volume)
• Battery Construction Material: 18650 (6) Battery Cell
• PPHP868ST Item Weight: 9.92 lbs.
PPHP868STBG Item Weight: 11.5 lbs
• Power Cable Length: 3.28 ft.
• Power Supply: DC 9V/1.5A
• Product Dimension (L x W x H)
PPHP868ST: 9.8" x 11.2" x 14.2" –inches
13.4" x 12.2" x 15" –inchesPPHP868STBG:
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including
interference that may cause undesired operation of the device.
- French:
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage; (2)L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20cm de distance entre la source
de rayonnement et votre corps.
California Prop 65 Warning
WARNING:
This product contains “Lead and lead compounds” which is
known to the state of California to cause cancer birth defects
and other reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
FCC INFORMATION
WARNING:
Changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This unit generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try and correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
WARNING
Illegal operation may cause personal injury, which could be fatal, and may
cause damage to property.
CONTROL BOARD FUNCTIONS
DO NOT place objects on top of the device, as objects may scratch
the device.
DO NOT expose the device to dirty or dusty environments.
DO NOT insert any foreign objects into the device.
DO NOT expose the device to strong magnetic or electrical elds.
DO NOT use the device in the rain.
Please check with your local authority or retailer for proper disposal
of electronic products.
DO NOT disassemble the device.
Only a certied service technician should perform repair.
The device has apertures to disperse heat.
DO NOT block the device ventilation; the device may become hot
and malfunction as a result.
14
15
16
17
3
4
5
6
7
8
9
10
11
12
13
1. Power Switch
2. FM antenna
3. Master Volume control
4. DC 9V input jack
5. 6.5MM microphone input jack
6. 3.5MM AUX input jack
7. USB
8. Micro SD
9. Microphone Echo control knob
10. Microphone volume control knob
11. Treble volume control knob
12. Bass volume control knob
13. Display screen
14. Previous
15. Play/Pause/Press and hold for
TWS function
16. Next
17. Mode button:
Short press to select BT/FM/AUX/
SD/USB mode.
Press and hold to turn ON/OFF
LED light.

Produkspesifikasjoner

Merke: Pyle
Kategori: Høyttaler
Modell: PPHP868ST
