1. General safety information
3. Improper use
Never use the DuoFern radio system and its components for
the remote control of appliances and systems with increased
safety-relevant requirements or where there is an accident
risk. This shall require additional safety equipment. Observe
the respective statutory regulations for the installation of
such systems.
The use of defective equipment can lead
to personal injury and damage to prop-
erty.
Never use defective or damaged equipment.
Please contact our Customer Service depart-
ment in this event .
2. Proper use
Proper use
Only use the DuoFern flush-mounted radio transmitter for
the remote control of DuoFern devices such as:
◆ DuoFern switch actuators
◆ DuoFern tubular motor actuators
◆ DuoFern tubular motors or DuoFern belt winders, etc.
Operating conditions
◆ Only use the DuoFern flush-mounted radio transmitter
in dry rooms.
◆ The installation and operation of the DuoFern radio
system and its components (e.g. DuoFern tubular
motor actuator) is only permitted for systems and de-
vices where a malfunction in the transmitter or receiver
would not cause a danger to personnel or property or
where this risk is already covered by other safety equip-
ment.
4.2 Functional description
The DuoFern flush-mounted radio transmitter enables exist-
ing commercially available switches or switch systems to be
upgraded with DuoFern radio technology. Multiple DuoFern
actuators or other DuoFern devices can be controlled with
the help of the connected switch and switches can be re-
motely controlled once the DuoFern flush-mounted radio
transmitter has been registered in the DuoFern network.
In addition, control signals from movement sensors or win-
dow contacts can be used for control purposes.
The mode setting and input configuration is realised with
the help of the two selector switches S1/S2.
Battery com-
partment
4.3 Configuration of the DuoFern radio transmitter and assignment of control commands
Connected
actuator
2 X SINGLE BUTTONS OR
1 X BUTTON IN SERIES
2 X SINGLE SWITCHES OR
1 X SWITCH IN SERIES
VENETIAN BLINDS BUTTON
VENETIAN BLINDS
SWITCH
SENSOR
FUNCTION *
(e. g. external
Window/Door Contact)
Applications Switch positions - S1 / S2
Switch actuator
e.g. DuoFern Universal
Actuator with
electrical appliance
Maximum 1 actuator per switch Maximum 16 actuators
Transmission > on / off on / off
Dimming actuator
e.g. DuoFern
Universal Dimmer
Maximum 1 actuator per switch Maximum 16 actuators
Transmission > on / stop / off / stop
Jog mode: light / dark
> 1 sec. on / off
Roller shutter /
Venetian blinds
actuators
e.g. DuoFern tubular
motor actuator
Maximum 1 actuator per switch Maximum 16 actuators Maximum 16 actuators
Transmission > up / stop / down / stop
Jog mode: up /down
> 1 sec. up / down
Up / Stop / Down
HomePilot®
Maximum 1 HomePilot® Maximum 16 HomePilot® Maximum 16 HomePilot® Maximum 16 HomePilot®
Transmission > Push on / off
Jog mode: up /down
> 1 sec. up / down
Up / Stop / Down Closed / Open
* Select this setting to use the DuoFern radio transmitter in HomePilot® as a sensor for „contact open / closed“.
4.1 General view - back
5.1 Installation procedure
1. If an additional mains-powered installation is
installed near the installation site. The mains
power must be deactivated prior to installation.
2. Electrical connection in accordance with chapter 7.
3. Register the DuoFern flush-mounted radio trans-
mitter in the DuoFern radio network, see chap-
ter 8.
4. Insert the DuoFern radio transmitter in the
flush-mounted box and lay the connecting cables
in the box.
ATTENTION ANTENNA CABLE
◆ Fit the antenna as straight as possible to ensure
the best possible reception.
5. Fit the connected potential-free button or switch.
6. Switch the mains power again back on again,
if necessary.
6. Dismantling
1. If an additional mains-powered installation is
installed near the installation site. The mains
power must be deactivated prior to disassembly.
2. Open the switch box.
3. Pull out the existing button / switch as well as
the DuoFern flush-mounted radio transmitter
from the switch box and disconnect them from
each other.
4. Restore the safe initial state of the switch
installation again.
4. General view - front
External power
supply 12 V / DC
Connect /
disconnect key
DIP switch
S1 / S2
Indicator LEDs
E1 / E2
Antenna (white) 4 x connecting leads:
E1 = ge + sw (yellow / black)
E2 = sw + gn (black / green)
Type plate
5. Assembly
During both installation and dismount-
ing of the DuoFern flush-mounted radio
transmitter there is a risk of fatal electric
shocks.
Observe the safety instructions for electrical
connection in chapter 7 prior to installation.
The DuoFern flush-mounted radio transmit-
ter is designed for flush-mounting only. We
recommend using a 58 mm deep box.
NOTE
In order to ensure optimal operation, the
DuoFern flush-mounted radio transmitter
should not be installed on a metallic base or
near metal objects.
Item No.: 3200 00 62
VBD 597-3 (01.20)
DuoFern radio transmitter 9497,
flush-mounted
Operating and Assembly Manual
3. Improper use
IMPORTANT
◆ Do not install the DuoFern radio transmitter outside.
◆ Never simultaneously connect / insert a battery and
external power supply. Doing so will damage the bat-
tery and may cause it to leak.
◆ The connecting wires may not be extended.
RADEMACHER
STATUS
9470-1
DuoFern 1-Kanal Aktor
K
L
L
N N
E
Made in Germany
RADEMACHER
STATUS
9471-1
DuoFern Rohrmotor-Aktor
L N
▲
▼
L N
E
▲
▼
Made in Germany
0 %
100%
