Side 1/18
10W SOLAR
BATTERY CHARGER
MAINTAINER
User Guide
Model: RSP10BM
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 03
SPECIFICATIONS
04
PACKAGE CONTENTS
04
INSTALLATION
05
INTELLIGENT CHARGING TECHNOLOGY
08
WARRANTY
09
- 01 - - 02 -
IMPORTANT SAFETY INSTRUCTIONS
PACKAGE CONTENTS
SPECIFICATIONS
Please read the User Guide carefully before installation.
IMPORTANT SYMBOLS
Indicates potentially dangerous conditions that could result in personal
injury
Indicates conditions or practices that could result in damages to the
unit or other equipment
Indicates procedures or functions that are important for proper and
safe operation of the unit and/or other equipment
CAUTION
DO NOT operate the unit if it has been smashed, squashed, pierced, or
otherwise damaged in anyway.
The unit is designed to withstand splashes and spills but is not fully
waterproof. DO NOT submerge the unit in water or leave it in the rain.
CAUTION
Dispose of the unit according to the local recycling and environmental
regulations.
CAUTION
DO NOT step, walk, stand, or jump on the unit. Localized heavy loads may
cause variances of micro-cracks on the solar cells, which will ultimately
compromise the reliability of the unit.
CAUTION
Clean the surface of the solar battery charger maintainer as necessary for
optimal performance.
WARNING
DO NOT disassemble the unit or remove any attached components.
Incorrect reassembly may result in a risk of fire or electric shock.
WARNING
Keep the unit out of reach of children unless supervised by an adult.
WARNING
WARNING
The unit is only compatible with 12V lead-acid batteries. DO NOT connect it
to other types of batteries or batteries with nominal voltages other than 12V.
Doing so may cause irreversible damages to the unit and/or battery explosion.
WARNING
To reduce the risk of a battery explosion, please follow the instructions
published by the battery manufacturer and review the cautionary markings
on the battery carefully.
WARNING
DO NOT place the unit on a surface constructed from combustible material.
Keep the unit away from explosives and corrosive substances.
WARNING
NOTE
NOTE
1 x Renogy 10W Solar Battery Charger Maintainer
1 x SAE to Ring Terminal Cable
1 x SAE to Alligator Clip Cable
1 x SAE to Cigarette Lighter Plug Cable
8 x Suction Cups
1 x User Guide
Rated Maximum Power
Open Circuit Voltage
Short Circuit Current
Optimum Operating Voltage
Optimum Operating Current
Operating Temperature Range
Output Connector
Dimension
Weight
10W
21.6V
0.61A
18V
0.56A
-4~140
/ -20~60
SAE
7.9 x 16.1 x 0.1 inch / 200 x 410 x 3 mm
15.8 oz / 447 g
- 03 - - 04 -
Solar Panel
MPPT Charge Controller
Boost Voltage
Float Voltage
Maximum Input Current
Maximum Output Current
Operating Temperature Range
14.8V
13.55V
0.7A
0.8A
-4~185
/ -20~85
