Installation & Operation
R1-1X10 R1-1X12
R1-2X10 R1-2X12
LOADED
ENCLOSURES
32
Dear Customer,
Congratulations on your purchase of the world’s finest brand of car audio
amplifiers. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford
Fosgate product installed by an Authorized Rockford Fosgate Dealer,
as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and
original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
jackets.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at 1-800-669-9899. Be sure to
have your serial number, model number and date of purchase available
when you call.
Enclosure Features
•High Current Binding Posts
•Constructed with 5/8” MDF
•Covered with High Density Carpet
Before installation, disconnect the battery nega-
tive (-) terminal to prevent damage to the unit,
fire and/or possible injury. Run the speaker
cable from the amp. When routing the speaker cable from the amplifier,
avoid running it close to any sources of high current (wiring harnesses).
The positive (+) speaker output from the amp connects to the red terminal
of the enclosure, and the negative (-) connects to the black terminal.
MISE EN GARDE: Avant d’entamer l’installation, déconnectez la broche
négative (-) de la batterie pour éviter tout risque de blessures, d’incendie
ou de dommages à l’appareil. Branchement du câble du haut-parleur de
l’amplificateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de
l’approcher d’une source de courant important. La sortie positive de l’ampli
se branche sur le terminal rouge du caisson, et le négatif se branche sur
le terminal noir.
PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo
de la batería (-) para prevenir daño a la unidad, incendio y/o posibles
lesiones. Recorrido del Cable de Altavoz Desde el Amplificador. Al llevar
el cable de altavoz desde el amplificador, evite que pase cerca de cualquier
fuente de alto corriente (cables de alimentacion). El terminal positive (+)
de las salida de rojo, y el terminal negativo (-) al terminal negro.
VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um
Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu vermeiden. An-
schluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables
sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel kreuzt,
um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherka-
bels kommt in die rote Klemme des Terminals, die Negativ-Leitung in die
schwarze Klemme des Terminals.
ATTENZIONE: Prima dell’installazione, scollegate il terminale negativo
(-) della batteria per evitare danni all’unità, pericoli d’incendio e/o poten-
ziali lesioni personali. Far correre il cavo dell’altoparlante all’amplificatore.
Quando fate correre il cavo dell’altoparlante all’amplificatore non fatelo
passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto.
Il segnale positivo dell’altoparlante (+) in uscita dall’amplificatore á col-
legato al terminale rosso del diffusore, e il negativo (-) al terminale nero.
Subwoofer Features
•Integrated Trim Ring
•Stamped Steel Basket
•12 AWG Compression Terminals
•Single Voice Coil
•Optimized for Sealed & Vented Enclosures
Introduction
©2014 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks of Rockford Corporation
in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à
100 dB peut causer une perte d’acuité auditive permanente. Les systèmes
audio de forte puissance pour auto peuvent produire des niveaux de
pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et
pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100
dB puede causar la pérdida permanente de la audición. Los sistemas de
sonido de alta potencia para automóviles pueden producir niveles de
presión de sonido superiores a los 130 dB. Aplique el sentido común y
practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über
130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und
praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica ben
superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole
del suono senza pericoli
Features
Model
R1-1X10 R1-2X10 R1-1X12 R1-2X12
Nominal Impedance 4 Ω 2 Ω 4 Ω 2 Ω
Replacement Woofer R1S4-10 R1S4-10 R1S4-12 R1S4-12
Power Handling (Watts) 200 RMS/400 Peak 400 RMS/800 Peak 200 RMS/400 Peak 400 RMS/800 Peak
Overall Dimensions
(HxWxD)
12.2” x 15.94” x 12.11”
(31cm x 40.5cm x 30.8cm)
12.2” x30.12” x 12.11”
(31cm x 76.5cm x 30.8cm)
14.37” x 34.06” x 12.51”
(36.5cm x 86.5cm x 31.8cm)
14.37” x 17.72” x 12.51”
(36.5cm x 86.5cm x 45cm)
CEA 2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle
power under continuous demand, not instantaneous power handling that over time can damage voice coils.
Specications
Installation
Red
Rojo
Rouge
Rot
Rosso
16 AWG
to
12 AWG
Black
Negro
Noir
Schwarz
Nero
R1-1X10 / R1-1X12
Amplifier: 4Ω Mono
Amplificateur: 4Ω Mono
Amplificador: 4Ω Mono
Amplifier: 4Ω Mono
Amplificatore: 4Ω Mono
From Amplifier From Amplifier
R1-2X10 / R2-1X12
Amplifier: 2Ω Mono
Amplificateur: 2Ω Mono
Amplificador: 2Ω Mono
Amplifier: 2Ω Mono
Amplificatore: 2Ω Mono
Strip 5/8”
(16mm)
CAUTION
